JST PAD Series 25V Crimp Wire, Neutral White Polyamide 66 Jacket, 300 mm Length 01SPHSPH-26001L300
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Voltage | 25V |
| Brand | JST |
| Model | 01SPHSPH-26001L300 |
| Cable Length | 300mm |
| Series | PAD |
| Jacket Material | Polyamide 66 |
| Wire size | 0.14mm² |
| Standards/Approvals | RoHS, R50053749, LR20812, E60389 |
| Connector Type A | SPH |
| Jacket Colour | Neutral White |
Key Features
- Suitable for wire size 0.14 mm² with insulation diameter between 1.0 and 1.5 mm.
- Features PAD series socket contacts made of tin-plated phosphor bronze for durability.
- Dual row 2.0 mm JST PAD connectors provide secure locking and polarization.
- High density connector design ensures reliable electrical continuity under adverse conditions.
- Wire jacket made of Polyamide 66 for chemical resistance and mechanical strength.
- Compliant with RoHS directives and meets standards R50053749, LR20812, E60389.
- Manufactured in the United Kingdom to ensure quality and reliability.
Product Description
JST 01SPHSPH-26001L300 PAD Series crimp wire is engineered for electrical and automation applications requiring reliable wire-to-board connections at 25 volts. The wire features a neutral white Polyamide 66 jacket with a length of 300 mm, optimized for secure and efficient connection performance.
The PAD Series socket contact is constructed from phosphor bronze and tin plated to support wire sizes ranging from 0.13 to 0.33 mm² (26 to 22 AWG) with insulation diameters from 1.0 to 1.5 mm. This crimp wire is double-ended with SPH-001T-P0.5L contacts crimped on both ends, designed for use with PADP series receptacle housings, making it ideal for high density electrical assemblies.
The 2.0 mm PAD series connectors are dual row and provide strong polarization features and secure locking to ensure continuous electrical contact even in adverse environments. This design helps maintain efficiency and durability in electrical circuits.
The jacket material Polyamide 66 offers excellent resistance to chemicals and physical wear, extending the wire’s service life in demanding applications. It also complies with RoHS standards and certifications including R50053749, LR20812, and E60389, supporting environmentally sound manufacturing requirements.
This product is manufactured in the United Kingdom, reinforcing stringent quality controls and product reliability. Suitable for wire size 0.14 mm² with insulation diameter between 1.0 and 1.5 mm. Phosphor bronze tin-plated PAD series contacts ensure excellent conductivity and corrosion resistance.
Dual row 2.0 mm JST PAD connectors provide secure locking and polarization. Durable Polyamide 66 jacket protects against harsh environments and mechanical stress. Complies with RoHS and other relevant certification standards.
Ideal for electronics manufacturing, automation, and wiring board connections. Manufactured in the United Kingdom with high quality standards. Explore more high-performance wire-to-board and crimp wire solutions in the Electronics & Electricals category at EnvMart.
Explore more products in our Crimped Wire category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for 25 volts, making it suitable for various electrical and automation applications.
The wire has a length of 300 mm, optimized for secure and efficient connection performance.
It features a jacket made of Polyamide 66, which provides chemical resistance and mechanical strength.
This crimp wire is suitable for wire sizes ranging from 0.13 to 0.33 mm² (26 to 22 AWG) with insulation diameters between 1.0 and 1.5 mm.
It uses SPH-001T-P0.5L contacts crimped on both ends, designed for compatibility with PADP series receptacle housings.
This model complies with RoHS directives and meets standards R50053749, LR20812, and E60389.
It is manufactured in the United Kingdom, ensuring stringent quality controls and product reliability.
The dual row 2.0 mm JST PAD connectors provide secure locking and polarization, ensuring reliable electrical continuity under adverse conditions.
It is ideal for electronics manufacturing, automation, and wiring board connections, where reliable wire-to-board connections are required.
The jacket of this crimp wire is neutral white, which is typical for many electrical applications.
The PAD series socket contacts are constructed from phosphor bronze and are tin plated to enhance conductivity and corrosion resistance.
The dual row design of the connectors helps maintain high density in electrical assemblies while ensuring secure locking and reliable contact.
