Mersen 355A Bolted Tag Fuse C1 gM High Speed 690V AC 133 mm Fixing Centres S1006634 / BTM69V355

Free Delivery in India | Lowest Global Shipping Charges

Mersen 355A Bolted Tag Fuse C1 gM High Speed 690V AC 133 mm Fixing Centres S1006634 / BTM69V355

Name: Mersen 355A Bolted Tag Fuse C1 gM High Speed 690V AC 133 mm Fixing Centres S1006634 / BTM69V355
Brand: Mersen
SKU: 244568
Price: 20.22 USD
Availability: InStock



Category Tag Fuses Brand Mersen Condition New

Specifications

Country of Origin	India
Voltage	690V ac
Diameter	59.1mm
Brand	Mersen
Height	75mm
Length	75mm
Model	S1006634 / BTM69V355
Width	59.1mm
Overall Length	212mm
Current Rating	355A
Series	Central Bolted Tag Fuse-links gM 690VAC/460VDC
Standards/Approvals	RoHS, EN 60269-2, CE, REACH
Fuse Size	C1
Fixing Centres	133 mm
Tag Width	26mm
Tag Orientation	Centred
Application Category	gM

Key Features

Designed for general purpose (gG) protection and motor protection (gM type).
High-speed fuse with fast fuse speed classified as F.
Fuse size C1 with a centred tag orientation for ease of installation.
Overall length of 212 mm and tag width of 26 mm.
Complies with RoHS, EN 60269-2, CE, and REACH standards.
Not designed for high rupture capacity applications.
Suitable for mounting in fuse holders or directly bolted to busbars.

Product Description

Mersen S1006634 / BTM69V355 Bolted Tag Fuse C1 is a robust industrial fuse designed for electrical circuit protection with a current rating of 355A and voltage rating of 690V AC. It features a bolted tag mounting style with 133 mm fixing centres, suitable for secure installation in fuse holders or directly on busbars. This fuse is engineered for general purpose use (gG type) protection as well as motor protection applications (gM type), ensuring excellent current limitation during overload conditions.

The fuse has a high-speed fuse speed classification (F), enabling rapid disconnection in fault conditions. It measures 212 mm in overall length with a tag width of 26 mm and a symmetrical centred tag orientation. The physical dimensions include a length and height of 75 mm each and a diameter of 59.1 mm, making it compatible with common fuseholders and disconnectors.

Manufactured under stringent quality standards, it meets RoHS, EN 60269-2, CE, and REACH compliance, affirming environmental and safety certifications. The fuse size C1 prohibits substitution with higher rated fuses within the same series to ensure safety and operational reliability.

This Central Bolted Tag Fuse-links gM series caters to applications requiring efficient overload protection in industrial, electrical automation, and motor circuit breaker systems. It is produced in India, guaranteeing local manufacturing standards and quality control.

General purpose and motor protection fuse (gG and gM type). High fuse speed rated F for quick fault response. Complies with major international standards for safety and environmental directives. Bolted mounting with 133 mm fixing centres for secure installation.

Physical dimensions optimized for fuseholders and disconnectors. Not suitable for high rupture capacity applications. Manufactured in India ensuring quality assurance.

This Mersen bolted tag fuse is essential for industrial electrical safety, delivering reliable circuit protection in diverse environments. For additional products in the tag fuse range, explore the extensive offerings available at EnvMart for electrical fuses and circuit protection devices.
