Mersen 6A Bolted Tag Fuse A2 690V AC Fuse - 73 mm Fixing Centres J1019253 / BTIA69V6

Free Delivery in India | Lowest Global Shipping Charges

Mersen 6A Bolted Tag Fuse A2 690V AC Fuse - 73 mm Fixing Centres J1019253 / BTIA69V6

Name: Mersen 6A Bolted Tag Fuse A2 690V AC Fuse - 73 mm Fixing Centres J1019253 / BTIA69V6
Brand: Mersen
SKU: 244517
Price: 20.22 USD
Availability: InStock



Category Tag Fuses Brand Mersen Condition New

Specifications

Country of Origin	India
Voltage	690V ac
Diameter	21.9mm
Brand	Mersen
Height	56.5mm
Length	56.5mm
Model	J1019253 / BTIA69V6
Width	21.9mm
Overall Length	86mm
Current Rating	6A
Series	Offset Tag fuse-links gG 690VAC/460VDC
Standards/Approvals	REACH, RoHS, CE, EN 60269-2
Fuse Size	A2
Fixing Centres	73 mm
Tag Width	9.2mm
Tag Orientation	Offset

Key Features

This bolted tag fuse has a current rating of 6 amperes for reliable circuit protection.
Fuse size is A2, compatible with fuseholders and busbars requiring 73 mm fixing centres.
The fuse operates at 690 volts AC with a high fuse speed (F) characteristic.
Constructed with an offset tag and 9.2 mm tag width ensuring secure mounting.
It complies with REACH, RoHS, CE and EN 60269-2 standards ensuring quality and safety.
The fuse is part of the offset tag fuse-links gG series suitable for AC and DC applications up to 460 V DC.

Product Description

Mersen J1019253 / BTIA69V6 6A Bolted Tag Fuse A2 690V AC is engineered for effective electrical circuit protection in industrial, commercial, and manufacturing settings. Designed primarily for general purpose use (gG type) or motor protection (gM type), this fuse ensures excellent current limitation to prevent overload damage.

The bolted tag construction enables secure installation by either screwing into fuseholders or direct bolting onto busbars or in fuse switch disconnectors, providing versatile application flexibility.

This fuse has a current rating of 6 amperes and operates safely at a voltage of 690 volts AC with a high fuse speed characteristic, suitable for circuits requiring fast interruption capability. Its fixing centres measure 73 mm with a tag width of 9.2 mm, optimized for compatibility with standard industrial fuse holders.

Key physical dimensions include a length of 56.5 mm, overall length of 86 mm, diameter and width of 21.9 mm, making it compact for integration into electrical panels. The offset tag orientation aids easy mounting and connection in electrical systems.

The product complies with important international standards including REACH, RoHS, CE, and EN 60269-2, assuring conformity to quality and environmental regulations. This bolted tag fuse offers precise circuit protection for AC and DC applications up to 690V AC and 460V DC.

Its high rupture capacity and fast fuse speed make it suitable for protecting motors and general purpose circuits. The robust construction ensures reliability even under demanding industrial conditions. The compact A2 fuse size enables replacement without risk of mismatching higher rated fuses.

Manufactured in India, the fuse stands for quality and dependable performance.

This Mersen bolted tag fuse finds extensive use in electrical distribution, motor protection, manufacturing plants, HVAC systems, and industrial automation environments. Its combination of safety features and industrial standard compliance makes it a trusted choice for circuit safety.

Explore the full range of Mersen Tag Fuses and related circuit protection devices on EnvMart to find the right fuse for your specific industrial and electrical needs.
