Mersen 800A Bolted Tag Fuse C3 415V AC Central Bolted Tag Fuse-links gG 415VAC/240VDC R226335 / BTLM42V800

Mersen R226335 / BTLM42V800 Bolted Tag Fuse C3 415V AC is a high-performance fuse designed for industrial and commercial electrical protection applications. It supports a current rating of 800A and voltage rating of 415V AC, suitable for both general purpose use (gG type) and motor protection (gM type). This fuse provides superior current limitation for overload protection across a wide range of use cases in electrical automation and power distribution systems.

The fuse size is C3 with a fast fuse speed classification F, enabling rapid interruption of fault currents. The fixing centres are set at 133 mm with a tag width of 26 mm, facilitating straightforward mounting either by screwing into fuse holders or bolting directly onto busbars. Its tag orientation is centred, making it compatible with standard fuseholders and fuse interruptors or disconnectors.

Manufactured in India, this fuse complies with stringent RoHS, REACH, CE, and EN 60269-2 standards to ensure safe and reliable operation. Its physical dimensions include an overall length of 212 mm, length of 86 mm, height and width of 86 mm and 82.4 mm diameter, constructed to withstand typical industrial electrical conditions.

This product is essential for electrical engineers and technicians requiring robust circuit protection solutions in industrial machines, electrical panels, motor starters, and automation systems. Its high rupture capacity rating caters to demanding electrical installations where dependable fuse operation is critical.

Designed for general purpose (gG type) or motor protection (gM type). Provides excellent current limitation for overloads. Fast fuse speed F rating for rapid fault interruption. 133 mm fixing centres with 26 mm tag width for installation ease.

Conforms to RoHS, REACH, CE, and EN 60269-2 standards. Physical dimensions: overall length 212 mm, length 86 mm, height 86 mm, diameter 82.4 mm, width 82.4 mm. Suitable for use in fuseholders, busbars, and fuse interruptors.
