Hongfa Europe GMBH PCB Power Relay 12V DC Coil 10A Switching Current SPDT HF3FA/012-ZTF
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 15.5mm |
| Length | 19mm |
| Model | HF3FA/012-ZTF |
| Width | 15.2mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | HF3FA |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | PCB Pin |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 400Ω |
| Coil Voltage | 12V dc |
| Switching DC Voltage | 28V dc |
| Switching AC Voltage | 250, 277V |
| Coil Power | 360mW |
Key Features
- High switching capacity supports up to 280W DC power.
- Low coil power consumption of 360mW ensures energy efficiency.
- Wide operating temperature range from -40°C to 85°C.
- Robust Silver Alloy contact material ensures durability and conductivity.
- Compact size with dimensions 19mm length, 15.5mm height, and 15.2mm width.
- PCB pin terminal type for secure mounting on circuit boards.
- Isolation voltage between coil and contacts is rated at 2.5KV AC.
- Complies with RoHS standards for environmental safety.
Product Description
Hongfa Europe GMBH HF3FA/012-ZTF PCB Power Relay is a subminiature, high-power non-latching electromagnetic relay designed for PCB mounting. Operating with a 12V DC coil, it offers a switching current of up to 10A and supports single pole double throw (SPDT) contact configuration. Its compact dimensions of 19mm length, 15.5mm height, and 15.2mm width allow ease of integration into various electronic assemblies.
Featuring a coil resistance of 400Ω and coil power of only 360mW, this relay provides sensitive operation while consuming minimal power. The relay functions efficiently across a wide temperature range from -40°C to 85°C, making it suitable for harsh industrial and automotive environments.
The SPDT contacts are constructed from durable Silver Alloy material and maintain a low contact resistance of 100 milliohms, ensuring reliable electrical connections. It operates with an isolation voltage of 2.5KV AC between coil and contacts for enhanced safety and compliance. Additionally, the HF3FA series meets RoHS environmental standards, reflecting its eco-friendly design.
Ideal for control applications in automotive, industrial automation, and electronic equipment, this relay serves as a robust switching component. It supports AC switching voltages of 250V and 277V and DC switching voltage up to 28V, with a maximum switching power of 2.8 kVA.
Mounting is achieved via PCB pins for secure and stable installation within circuit designs. The product is manufactured in China and is provided in new condition suitable for professional industrial use.
High switching capacity up to 280W DC. Low coil power consumption at 360mW ensures efficiency. Wide operating temperature range from -40°C to 85°C. Durable Silver Alloy contacts offer reliability. Compact design with 19mm × 15.5mm × 15.2mm dimensions.
PCB pin terminals for secure mounting. 2.5KV AC isolation voltage between coil and contacts. RoHS compliant for environmental safety. Low contact resistance at 100mΩ for efficient conductivity. Discover more Power Relay solutions and accessories on EnvMart to support your industrial, automotive, and electronic application needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay has a switching current capacity of up to 10A.
This model has dimensions of 19mm in length, 15.5mm in height, and 15.2mm in width.
The coil voltage for this relay is 12V DC.
It uses a single pole double throw (SPDT) contact configuration.
The relay operates within a temperature range of -40°C to 85°C.
The coil power consumption is 360mW.
The isolation voltage between the coil and contacts is rated at 2.5KV AC.
The contacts are made from durable Silver Alloy material.
The contact resistance is 100 milliohms.
Yes, this relay complies with RoHS standards for environmental safety.
It supports AC switching voltages of 250V and 277V, and DC switching voltage up to 28V.
This relay is mounted using PCB pin terminals for secure installation on circuit boards.
