Hongfa Europe GMBH PCB Power Relay, 12V DC Coil, 30A Switching Current, SPST HF165FD/12-HY1TF
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 20.4mm |
| Length | 32.2mm |
| Model | HF165FD/12-HY1TF |
| Width | 27.5mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | HF165FD |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -40°C |
| Switching Current | 30A |
| Terminal type | PCB Pin |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 155Ω |
| Coil Voltage | 12V dc |
| Switching AC Voltage | 277V ac |
| Coil Power | 900mW |
Key Features
- This relay supports a coil voltage of 12V DC and features a single pole single throw (SPST) contact configuration.
- The switching current rating is 30A, suitable for switching loads up to 8.3 kVA.
- Operating temperature ranges from -40°C to 85°C, enabling use in industrial environments.
- Silver alloy contact material improves electrical endurance and reliability.
- Coil resistance is 155 ohms with a coil power consumption of 900mW ensuring low power usage.
- RoHS compliant, ensuring environmental friendliness and safety standards adherence.
- The relay offers high surge withstand voltage of 6kV and mechanical endurance rated up to 10 million cycles.
- Ideal applications include industrial machinery, household appliances, automotive controls, and telecommunications.
Product Description
Hongfa Europe GMBH HF165FD/12-HY1TF is a high-performance PCB power relay equipped with a 12V DC coil and SPST contact configuration. It supports a switching current of 30A and switching AC voltage up to 277V, suitable for a variety of demanding industrial and commercial applications.
Constructed with silver alloy contacts to ensure long electrical endurance and low contact resistance of 100mΩ, this relay offers reliable switching performance over a wide temperature range from -40°C to 85°C. It is RoHS compliant, which confirms adherence to environmental safety requirements.
The relay features a compact footprint with dimensions 32.2mm (L) x 27.5mm (W) x 20.4mm (H) that conserves board space and allows easy integration onto printed circuit boards via PCB pin terminals. With a coil resistance of 155 ohms and coil power consumption of just 900mW, it provides efficient electrical control.
Designed for robust industrial usage, it withstands high surge voltages up to 6kV and mechanical shocks, maintaining mechanical endurance of up to 10 million cycles. This makes it suitable for use in automotive industry controls, household appliance circuits, industrial automation equipment, and telecom devices.
Thanks to its environmental resilience and compact design, this power relay is ideal for applications requiring reliable switching under harsh conditions. It offers excellent board space savings while ensuring stable and efficient operation.
12V DC coil voltage with SPST contact configuration. 30A switching current and 8.3 kVA switching power rating. Operating temperature range from -40°C to 85°C with high surge voltage withstand. Silver alloy contacts for low resistance and high endurance.
Compact size perfect for PCB mounting with PCB pin terminals. RoHS compliant and environmentally friendly. Mechanical endurance of 10 million cycles ensures long product life. Applications in automotive, household appliances, industrial machinery, and telecom.
Explore more Power Relays and related components in the Electronics & Electricals category at EnvMart for your industrial, commercial, and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay has a switching current rating of 30A, making it suitable for switching loads up to 8.3 kVA.
This model operates with a coil voltage of 12V DC.
It features a single pole single throw (SPST) contact configuration.
The operating temperature range is from -40°C to 85°C, allowing for use in various industrial environments.
The relay is constructed with silver alloy contacts, which enhance electrical endurance and reliability.
The dimensions are 32.2mm in length, 27.5mm in width, and 20.4mm in height.
The coil resistance is 155 ohms, and the coil power consumption is 900mW.
It has a mechanical endurance rated for up to 10 million cycles.
The relay can switch AC voltage up to 277V.
Yes, the relay is RoHS compliant, ensuring it meets environmental safety standards.
It is suitable for applications in industrial machinery, household appliances, automotive controls, and telecommunications.
