Hongfa Europe GMBH PCB Power Relay 5V DC Coil 10A Switching Current SPDT HF3FA/005-ZTF
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 15.5mm |
| Length | 19mm |
| Model | HF3FA/005-ZTF |
| Width | 15.2mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | HF3FA |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | PCB Pin |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 70Ω |
| Coil Voltage | 5V dc |
| Switching DC Voltage | 28V dc |
| Switching AC Voltage | 250, 277V |
| Coil Power | 360mW |
Key Features
- The relay offers a compact design with 15.5mm height, 19mm length, and 15.2mm width dimensions.
- It operates reliably across a temperature range of -40°C to 85°C.
- Coil resistance is 70Ω, with a coil power of 360mW ensuring low power consumption.
- Silver alloy contacts provide durable contact reliability with a contact resistance of 100mΩ.
- The relay supports switching voltages of up to 28V DC and AC voltages of 250 and 277V.
- It is a PCB mount type with PCB pin terminals for easy integration.
- The relay meets RoHS standards, suitable for automotive and control device applications.
Product Description
Hongfa Europe GMBH HF3FA/005-ZTF PCB Power Relay is a high-quality SPDT type power relay designed for demanding electronic applications. It features a 5V DC coil and a switching current capacity of 10A, making it suitable for both industrial and automotive control systems.
The relay's compact size with dimensions of 15.5mm height, 19mm length, and 15.2mm width enables efficient PCB mounting. Its silver alloy contacts ensure reliable conductivity and long service life. The 70Ω coil resistance paired with 360mW coil power enables energy-efficient operation while maintaining robust switching performance.
Operating reliably in harsh environments, this relay functions within a broad temperature range from -40°C to 85°C. It supports a switching DC voltage of up to 28V and AC voltages of 250 and 277V, providing versatility across various applications.
The PCB pin terminal type and RoHS compliance further ensure that this relay meets modern environmental and manufacturing standards. Its design includes a sealed plastic body that protects the internal components from dust and contaminants, enhancing durability and operational stability.
This relay is ideal for use in control devices, automotive electronics, and industrial automation where compact size and dependable switching are critical. It is engineered to offer excellent performance with low coil power consumption and high contact capacity, making it an efficient solution for electrical control requirements.
The relay offers a compact design with 15.5mm height, 19mm length, and 15.2mm width dimensions. It operates reliably across a temperature range of -40°C to 85°C. Coil resistance is 70Ω, with a coil power of 360mW ensuring low power consumption.
Silver alloy contacts provide durable contact reliability with a contact resistance of 100mΩ. The relay supports switching voltages of up to 28V DC and AC voltages of 250 and 277V. It is a PCB mount type with PCB pin terminals for easy integration.
The relay meets RoHS standards, suitable for automotive and control device applications. Explore more advanced Power Relays and electronic components in the Electronics & Electricals category at EnvMart for reliable industrial and commercial solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a switching current capacity of 10A, making it suitable for various industrial and automotive applications.
The relay has a compact design with dimensions of 15.5mm in height, 19mm in length, and 15.2mm in width.
It operates with a coil voltage of 5V DC, ensuring compatibility with low voltage applications.
The relay operates reliably across a temperature range of -40°C to 85°C, making it suitable for harsh environments.
This model features a Single Pole Double Throw (SPDT) contact configuration, allowing for versatile switching options.
The contact resistance is 100mΩ, which contributes to its reliable conductivity.
The coil resistance is 70Ω, which helps in determining the power consumption of the relay.
It supports switching DC voltages of up to 28V and AC voltages of 250V and 277V, providing versatility for various applications.
The contacts are made of silver alloy, which enhances contact reliability and durability.
This unit is designed for PCB mounting with PCB pin terminals, facilitating easy integration into electronic circuits.
Yes, it meets RoHS standards, ensuring it adheres to modern environmental and manufacturing regulations.
The coil power is 360mW, which ensures low power consumption during operation.
