Hongfa Europe GMBH PCB Power Relay 12V dc Coil 10A Switching Current SPDT HF3FA/012-ZTF
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 15.5mm |
| Length | 19mm |
| Model | HF3FA/012-ZTF |
| Width | 15.2mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | HF3FA |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | PCB Pin |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 400Ω |
| Coil Voltage | 12V dc |
| Switching DC Voltage | 28V dc |
| Switching AC Voltage | 250, 277V |
| Coil Power | 360mW |
Key Features
- This relay includes silver alloy contacts ensuring reliable conductivity.
- It supports a switching power of up to 2.8 kVA for AC and 28V DC voltage capability.
- The coil power consumption is low at 360mW for sensitive operation.
- Designed for PCB mounting with PCB pin terminals for easy installation.
- Operating temperature range extends from -40°C to 85°C for diverse environmental conditions.
- Compact dimensions feature a height of 15.5mm, length of 19mm, and width of 15.2mm.
- The contact resistance remains low at 100mΩ to reduce power losses.
- This SPDT relay provides 1 Form C type contact arrangement with non-latching function.
Product Description
Hongfa Europe GMBH HF3FA/012-ZTF PCB Power Relay is a high power, non-latching electromagnetic relay featuring a 12V DC coil and SPDT contact configuration. With a switching current capacity of 10A and switching power of 2.8 kVA AC and 28V DC, it effectively handles medium power control tasks on printed circuit boards.
Its silver alloy contacts provide excellent conductivity and wear resistance. The relay has a coil resistance of 400Ω and requires a mere 360mW coil power for actuation, making it energy efficient. It supports a broad operating temperature range from -40°C to 85°C, suitable for demanding industrial environments.
The compact relay is designed for PCB mounting using PCB pin terminals and has precise dimensions of 15.5mm height, 19mm length, and 15.2mm width. The contact resistance is kept low at 100mΩ to ensure stable performance. This relay conforms to RoHS standards and is made in China.
Applications typically include automotive industry control, various electrical automation uses, and any situation requiring a reliable single pole double throw switching device. Its plastic sealed type enclosure offers durability and safety in electrical circuits.
This relay includes silver alloy contacts ensuring reliable conductivity. It supports a switching power of up to 2.8 kVA for AC and 28V DC voltage capability. The coil power consumption is low at 360mW for sensitive operation.
Designed for PCB mounting with PCB pin terminals for easy installation. Operating temperature range extends from -40°C to 85°C for diverse environmental conditions. Compact dimensions feature a height of 15.5mm, length of 19mm, and width of 15.2mm.
The contact resistance remains low at 100mΩ to reduce power losses. This SPDT relay provides 1 Form C type contact arrangement with non-latching function. Isolation voltage between coil and contact is rated at 2.5 kVAC. Applicable in automotive, industrial control and automation applications.
Explore the range of Power Relays at EnvMart for enhanced control solutions in your electrical and automation projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay has a switching current capacity of 10A.
This model operates with a 12V DC coil voltage.
It supports a maximum switching power of 2.8 kVA for AC and 28V DC.
The relay has dimensions of 15.5mm in height, 19mm in length, and 15.2mm in width.
It features a Single Pole Double Throw (SPDT) contact configuration.
The operating temperature range extends from -40°C to 85°C.
The contact resistance is low at 100mΩ, which helps reduce power losses.
It is designed for PCB mounting using PCB pin terminals for easy installation.
The coil power consumption is 360mW, making it energy efficient.
Yes, it conforms to RoHS standards.
The contacts are made from silver alloy, ensuring reliable conductivity.
It is typically used in automotive industry control, electrical automation, and situations requiring reliable SPDT switching.
