Hongfa Europe GMBH PCB Power Relay, 24V DC Coil, 20A Switching Current, SPDT Contact Configuration HF115F-L/24-Z3L2TF

Hongfa Europe GMBH HF115F-L/24-Z3L2TF PCB Power Relay is a compact, high-performance power relay designed for PCB mounting with a 24V DC coil voltage and 20A switching current capacity. It offers a single pole double throw (SPDT) contact configuration suitable for a wide variety of electrical and industrial applications.

The relay’s compact form factor with a height of 15.7mm, length of 29mm, and width of 12.7mm ensures easy integration on printed circuit boards. It features silver alloy contacts that provide low contact resistance of 100 milliohms, enhancing electrical reliability and longevity under demanding conditions.

This relay supports switching AC and DC voltages up to 440V AC and 300V DC respectively, and has a coil power consumption of 600mW with a coil resistance of 1440 ohms. Its operating temperature range from -40°C up to 85°C enables use in diverse industrial environments.

The product is RoHS compliant, environmentally friendly, flux proofed, and plastically sealed for durability and safety. Isolation voltage between coil and contact reaches 5KV AC, which ensures high voltage endurance and protects sensitive circuitry.

Suitable for automotive engines, household appliances, industrial machinery, medical devices, and telecommunication equipment, this relay offers robust and reliable switching. Its PCB terminal mounting type provides secure and convenient installation on circuit boards.

This relay features a high switching power capacity of up to 4KVA in AC applications. The product supports durability up to 2 million cycles ensuring long service life. Plastic sealed and flux proof construction enhances environmental protection.

Silver alloy contacts assure efficient conduction and low resistance. Operating temperature range from -40°C to 85°C. Isolation voltage between coil and contact is rated at 5K VAC. Compliant with RoHS environmental standards.

Ideal for automotive, industrial, medical, and telecommunication use cases.

This Hongfa Europe GMBH PCB Power Relay HF115F-L/24-Z3L2TF is a reliable and compact solution for demanding circuit control and switching needs in electronic manufacturing and industrial sectors. For a comprehensive selection of relays and electrical components, browse the Electronics & Electricals category on EnvMart.
