TE Connectivity AMPMODU MOD II Series Straight Through Hole PCB Socket, 4-Contact, 1 Row, 2.54 mm Pitch Solder 5-534237-2

Free Delivery in India | Lowest Global Shipping Charges

TE Connectivity AMPMODU MOD II Series Straight Through Hole PCB Socket, 4-Contact, 1 Row, 2.54 mm Pitch Solder 5-534237-2

Name: TE Connectivity AMPMODU MOD II Series Straight Through Hole PCB Socket, 4-Contact, 1 Row, 2.54 mm Pitch Solder 5-534237-2
Brand: TE Connectivity
SKU: 238508
Price: 1.14 USD
Availability: InStock



Category PCB Socket Brand TE Connectivity Condition New

Specifications

Country of Origin	China
Voltage	333V
Brand	TE Connectivity
Orientation	Straight
Current	12A
Mount Type	Through Hole
Housing Material	Liquid Crystal Polymer
Contact Material	Gold
Series	AMPMODU MOD II
Termination Type	Solder
Maximum Operating Temperature	105°C
Sub Type	Board-to-Board
Minimum Operating Temperature	-65°C
Number of Rows	1
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	4
Contact Gender	Female
Connector System	Board-to-Board

Key Features

This PCB socket is made of liquid crystal polymer housing for high temperature resistance.
It supports a voltage rating of 333V and current of 12A.
The socket features gold plated female contacts ensuring reliable connectivity and corrosion resistance.
It is designed as a straight orientation through hole mount socket suitable for solder termination.
The operating temperature range is from -65°C to 105°C for diverse environmental conditions.
The AMPMODU MOD II series ensures compact and stackable interconnect solutions for industrial electronics applications.
The product is manufactured in China and intended for board-to-board connector system applications.

Product Description

TE Connectivity 5-534237-2 is an AMPMODU MOD II Series Straight Through Hole PCB Socket featuring 4 contacts arranged in a single row with a 2.54 mm pitch. This product is engineered to deliver reliable board-to-board connections in industrial, automation, control, and electronic manufacturing applications.

The socket is constructed from high temperature resistant liquid crystal polymer housing compatible with solder termination through hole mounting. It supports an electrical rating of 333V and 12A current handling capability. The female contacts are gold plated for enhanced connectivity and corrosion protection, enhancing performance in demanding environments.

The product operates efficiently within a temperature range of -65°C to 105°C, ensuring durability and long life in various industrial settings. The straight orientation design allows seamless integration into printed circuit boards, maintaining a compact footprint essential for modern electronic systems.

The AMPMODU MOD II interconnect system, of which this socket is a part, provides signal standard solutions for automation and control systems, emphasizing reliability and economical design. Its closed-entry housing prevents post stubbing, ensuring protection during assembly and operation.

This PCB socket uses liquid crystal polymer housing for heat resistance. Gold plated female contacts offer durability and consistent performance. Designed for through hole solder mounting with 2.54 mm pitch. Rated for 333V voltage and 12A current.

Operating temperature range spans -65°C to 105°C. Compact modular design supports board-to-board connections in control systems. Manufactured in China to meet quality standards.

This PCB socket is ideal for use in electronic assembly, automation equipment, communication devices, and industrial control panels. It enables secure and efficient signal connection where space and reliability are critical factors. Browse more PCB Sockets from TE Connectivity for compatible solutions and industrial-grade connectors.
