Myrra 24 V AC 2 Output PCB Transformer 30 VA, Encapsulated Type EI 54 / 18.8, Isolation Voltage 4 kV, 230 V Primary 44312

Myrra 44312 is a high-quality 24 V AC PCB Transformer featuring dual outputs and a power rating of 30 VA. Designed with encapsulated EI 54 / 18.8 core construction, it is optimized for printed circuit board mounting in electronic components and power supply applications.

This PCB transformer operates at a primary voltage of 230 V AC and delivers a nominal secondary voltage of 24 V AC. It supports two separate output windings, making it suitable for dual voltage supply needs.

With an isolation voltage rating of 4 kV, the Myrra 44312 provides enhanced safety to protect sensitive electronics and operators. The transformer complies with stringent international standards including EN 61558-2-6 for safety of power transformers, EN 60950 for information technology equipment, and UL 1585 certifications.

The product can withstand maximum ambient temperatures up to 250°C, allowing reliable performance in industrial environments. Operating frequency ranges from 50 Hz to a maximum of 60 Hz, suitable for common electrical supply scenarios worldwide.

Physical dimensions are compact with a length of 56.5 mm, width of 47.25 mm, and depth of 38.75 mm. Its lightweight design at 400 g simplifies integration into controlled environments and electronic assemblies. The mount type is PCB, facilitating straightforward fixing on printed circuit boards.

Primary voltage 230 V AC. Secondary voltage 24 V AC. Dual output configuration. Rated power: 30 VA. Isolation voltage 4 kV. Compliance: EN 61558-2-6, EN 60950, UL 1585. Operating temperature up to 250°C. Dimensions: 56.5 x 47.25 x 38.75 mm.

Weight: 400 g. Frequency range: 50-60 Hz.

This Myrra PCB Transformer is ideal for use in power supplies, industrial control systems, electronic devices, and other commercial or laboratory applications requiring reliable voltage transformation and isolation.
