Myrra PCB Transformer 24 V ac 2 Output Through Hole, 2 VA, EN 61558-2-6, EN 60950, UL 5085 44132

Free Delivery in India | Lowest Global Shipping Charges

Myrra PCB Transformer 24 V ac 2 Output Through Hole, 2 VA, EN 61558-2-6, EN 60950, UL 5085 44132

Name: Myrra PCB Transformer 24 V ac 2 Output Through Hole, 2 VA, EN 61558-2-6, EN 60950, UL 5085 44132
Brand: Myrra
SKU: 237793
Price: 8.88 USD
Availability: InStock



Category PCB Transformer Brand Myrra Condition New

Specifications

Country of Origin	France
Brand	Myrra
Length	32.6mm
Model	44132
Depth	27.3mm
Gross Weight	100g
Width	27.6mm
Mount Type	Through Hole
Maximum Operating Temperature	70°C
Number of outputs	2
Winding Type	Dual Secondary, Single Primary
Standards/Approvals	EN 61558-2-6EN 60950UL 5085
Primary Voltage	230 V ac
Secondary Voltage	24 V ac
Minimum Operating Frequency	50Hz
Maximum Operating Frequency	60Hz
PCB Transformer Current	42mA
Myrra 24 V ac 2 Output Through Hole PCB Transformer, EN 61558-2-6 1.5 VABrand	Myrra

Key Features

This transformer operates with a primary voltage of 230 V ac.
It features a length of 32.6mm, width of 27.6mm, and depth of 27.3mm.
The device supports a maximum operating temperature of 70°C and frequency range of 50 Hz to 60 Hz.
The winding type includes a single primary and dual secondary configuration.
Designed with professional safety insulation above 4000 V for reliable and safe operation.
Manufactured complying with EN 61558-2-6, EN 60950, and UL 5085 standards ensuring industrial safety compliance.
Ideal for use in electronic equipment requiring PCB-mounted transformers with 2 VA power rating.
Supports coupling in series or parallel configurations for flexible design integration.

Product Description

Myrra 44132 is a PCB Transformer designed for electronic applications requiring a 24 V ac dual secondary output. This transformer offers 2 VA power rating with a through hole mount type suitable for printed circuit board applications. It operates at 230 V ac primary voltage and functions safely within a temperature range up to 70°C. The winding configuration consists of a single primary and dual secondary output rated for 42 mA current, ensuring effective current supply for various electronic circuits.

This device meets stringent safety standards including EN 61558-2-6, EN 60950, and UL 5085, making it reliable for professional and industrial use. Its construction with vacuum-filled resin and non-flammable, self-extinguishing materials ensures durability, high insulation resistance (above 4000 V), and short circuit protection. The compact dimensions (32.6 mm length, 27.6 mm width, 27.3 mm depth) make it ideal for tight PCB layouts.

Applications include power supplies, electronic control units, telecommunications equipment, and other industrial electronics requiring robust and safe voltage transformation. The transformer is manufactured in France, leveraging high-quality construction processes. Note that fixing screws are not provided with the unit.

This transformer supports coupling in series or parallel configurations for flexible design integration. It undergoes 100% automated quality control ensuring product consistency and reliability. Compact through hole design simplifies PCB soldering and integration into electronic assemblies.

Operational frequencies between 50 Hz and 60 Hz allow compatibility with global power standards. Its 2 output configuration enables dual voltage supply requirements from a single transformer source. Explore more PCB Transformers by Myrra available at EnvMart for your power supply and electronics projects.
