Myrra SMPS Transformer 12 Output, 5.4 W Power, 265 V AC Primary Voltage, 3.3 to 24 V Secondary Voltage Model 47126

Myrra 47126 SMPS Transformer is a compact, efficient switched mode power supply transformer offering 12 regulated DC outputs with a total power of 5.4 W. It is engineered for industrial and consumer electronics use, featuring primary voltages of 265 V AC and 370 V DC, and secondary voltage outputs ranging from 3.3 V to 24 V. The transformer supports a maximum secondary current of 1350 mA.

Operating temperature ranges from -40°C to 85°C, ensuring dependable performance under diverse environmental conditions. The transformer has a high isolation voltage of 4000 V AC, providing electrical safety in sensitive applications.

Certified to stringent standards including EN 55014-1/-2, EN 61000-4-x series, EN 55022 Class B, EN 60950, EN 60335, UL 94-V0, and EN 61558-2-17, this transformer ensures compliance with EMC and safety regulations. Its flyback topology based switched mode power supply design offers reduced energy consumption and low standby power, making it an energy-saving alternative to traditional transformers.

This SMPS transformer, with a footprint similar to an EI30 type, consolidates the functionalities of a transformer, fuse, bridge rectifier, regulator, and filtering capacitor into a single device, improving efficiency and reducing component count on PCBs.

Common applications include telecom power supplies, electric substations, industrial automation systems, and various domestic and consumer electronics requiring stable DC voltage outputs.

This transformer operates at a primary voltage of 265 V AC and 370 V DC. It delivers a secondary voltage range from 3.3 to 24 V with a secondary current of 1350 mA. Designed to function in temperatures ranging from -40°C up to 85°C for reliable operation.

Features an isolation voltage rating of 4000 V AC to ensure electrical safety and protection. The device conforms to multiple standards including EN 55014, EN 60950, and UL 94-V0 for safety and EMC compliance. Utilizes a switched mode power supply flyback topology for energy efficiency and compact design.

Suitable for use in telecom supplies, electric substations, and a wide range of industrial, domestic, and consumer electronics. This product is made in China and is supplied in new condition. Explore the wide range of SMPS Transformers and power supply components available on EnvMart for your electronic design and industrial needs.
