Myrra 2 Output SMPS Transformer, Primary Voltage 265 V ac 370 V dc, Isolation Voltage 4000V ac, Model 47114

Myrra 47114 is a 2 Output SMPS Transformer featuring a primary voltage of 265 V AC and 370 V DC with isolation voltage of 4000V AC. This encapsulated electronic transformer utilizes switched mode power supply technology based on Flyback topology, providing a reliable and efficient power source with low standby power consumption.

It operates effectively within a temperature range of -25°C to 70°C, making it suitable for various industrial and consumer electronics environments. The compact form factor closely matches the footprint of a standard EI30 transformer, enabling direct replacement of traditional transformers, fuse, bridge rectifier, and filtering capacitor combinations.

This transformer complies with multiple standards for safety and electromagnetic compatibility, including EN 55014-1, EN 55014-2, UL 94-V0, EN 61000-4-x, EN 61558-2-17, EN 60335, EN 55022 Class B, and EN 60950. The unit is designed for frequencies from 47Hz to 440Hz, providing a robust solution for power requirements under 5W.

The transformer provides 2 unregulated DC outputs for flexible circuit integration. Its high isolation voltage rating of 4000V AC ensures safety and reliability in demanding applications. Ideal for telecom supplies, electric substations, and various industrial applications.

The efficient design helps conserve energy and reduce operating costs. Applications include industrial, domestic, and consumer electronics with power levels below 5 watts. The transformer is manufactured in China and belongs to the 47000 series.

With compact dimensions, it facilitates straightforward PCB mounting and system integration.

This SMPS transformer is a practical alternative to traditional transformers, simplifying design while maintaining performance and compliance with international standards. Browse EnvMart for more Myrra power supply components and industrial SMPS Transformers.
