Alpha Wire FIT Wire Management Series Slate Chloroprene Rubber Polyamide Cable Gland PG29 Thread 18-25 mm PPC29 SL080
Specifications
| Country of Origin | India |
|---|---|
| Brand | Alpha Wire |
| Material | Chloroprene Rubber, Polyamide |
| Colour | Slate |
| Temperature range | -20°C to +100°C (Permanent), -30°C to +150°C (Intermittent) |
| Model | PPC29 SL080 |
| IP Rating | IP66, IP68 |
| Series | FIT Wire Management |
| Maximum Operating Temperature | 150°C |
| Thread Size | PG29 |
| Minimum Operating Temperature | -20°C |
| Thread Length | 11 mm |
| Clamping Range | 18 - 25 mm |
| Thread Diameter | 37 mm |
| Standards/Approvals | CSA C22.2, UL 514, UL 94V-2 |
| Maximum Cable Diameter | 25mm |
| Minimum Cable Diameter | 18mm |
| Flammability | V2 (According to UL94) |
Key Features
- Constructed with slate chloroprene rubber and polyamide materials for robustness.
- Features PG29 thread size with 11 mm thread length and 37 mm thread diameter.
- Rated for IP66 and IP68 protection, safe for dust and water immersion applications.
- Operates in temperatures from -20°C to 150°C, suitable for intermittent high temperatures.
- Includes a locknut for secure mounting and compliance with CSA C22.2, UL 514, and UL 94V-2 standards.
- Flammability rating V2 ensures flame resistance as per UL94 testing.
- Ideal for use in telecommunications, control, instrumentation, and electrical power systems.
Product Description
Alpha Wire PPC29 SL080 is a high-quality cable gland from the FIT Wire Management Series designed for effective cable strain relief and protection in industrial and commercial applications. Featuring a polyamide 6 body combined with a chloroprene rubber O-ring/seal, this cable gland offers durable performance and resistance against environmental factors.
The gland accommodates cables with a diameter range of 18 to 25 mm and utilizes a PG29 threaded design with an 11 mm thread length and 37 mm thread diameter. Its slate color complements equipment aesthetics while providing functional sealing.
Certified to meet IP66 and IP68 ratings, the cable gland withstands dust ingress and submersion in water up to 5 bar pressure for 30 minutes, making it suitable for harsh environments. The operational temperature range spans from -20°C to +100°C permanently, with intermittent tolerance up to +150°C, supporting diverse thermal conditions.
Constructed to comply with CSA C22.2, UL 514, and UL 94V-2 standards, this product ensures safety and flammability performance tested under UL94, achieving a V2 rating which means flames self-extinguish within 30 seconds on vertical plastic parts.
Robust chloroprene rubber and polyamide construction. Wide cable clamping range of 18 to 25 mm. IP66 and IP68 dust and water ingress protection ratings. Temperature rating from -20°C to +150°C intermittent. Includes locknut for secure installation.
Compliant with internationally recognized electrical and flammability standards. Suitable for telecommunications, instrumentation, and power cable applications.
This cable gland supports industrial, electrical automation, and telecommunications infrastructure, providing reliable strain relief and environmental protection. Choose Alpha Wire for quality cable fittings that maintain system integrity and safety. Browse our Electronics & Electricals section for more cable management solutions at EnvMart.
Explore more products in our Cable Glands & Fittings category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The cable gland operates in a temperature range of -20°C to +100°C for permanent use, and it can tolerate intermittent temperatures up to +150°C.
This cable gland is rated for IP66 and IP68 protection, making it suitable for applications that require resistance to dust ingress and water immersion.
It accommodates cables with a diameter range of 18 mm to 25 mm.
It is constructed from chloroprene rubber and polyamide, providing durability and resistance to environmental factors.
The thread size is PG29, with a thread length of 11 mm and a thread diameter of 37 mm.
It complies with CSA C22.2, UL 514, and UL 94V-2 standards, ensuring safety and performance in various applications.
Yes, it includes a locknut for secure mounting during installation.
It has a flammability rating of V2 according to UL94, meaning flames self-extinguish within 30 seconds on vertical plastic parts.
It is suitable for telecommunications, control, instrumentation, and electrical power systems.
The cable gland is manufactured in India.
The maximum cable diameter that this gland can accommodate is 25 mm.
The minimum operating temperature for this model is -20°C.
