TE Connectivity AMPSEAL 16 Automotive Connector Male Red Clip 12 Way Crimp Termination 776438-1

TE Connectivity 776438-1 AMPSEAL 16 Automotive Connector is a male, sealed pin housing designed for automotive electrical systems requiring reliable and secure connections. This 12 way crimp termination connector features a red clip housing constructed from robust fibreglass reinforced polybutylene terephthalate material, ensuring dependable mechanical and environmental performance.

The connector offers 12 contacts in two rows, designed to handle 13 amperes of current. It’s rated IP67, providing excellent protection against dust and water ingress, which is critical for harsh automotive environments. With a temperature operating range from -40°C to 125°C, it meets the thermal demands commonly experienced under vehicle hoods and other automotive compartments.

Featuring a clip mount type, the AMPSEAL 16 connector secures firmly in place and includes colour coding and physical keying to prevent mismating with incompatible components. The connector accommodates a wire size range of 2.18 to 3.67 mm, fitted with a standard diameter wire seal ensuring environmental sealing.

This product complies with EU RoHS and EU ELV legislation, supporting environmental and safety regulations. Its compact form factor, measuring 37.6mm width, 26.65mm height, and 47.55mm depth, facilitates easy integration into vehicle electrical assemblies.

Ideal for automotive manufacturing, repair, and maintenance applications, the TE Connectivity AMPSEAL 16 connector delivers dependable, sealed electrical connections required in modern vehicles. Whether used in wiring harnesses or critical system interconnections, it ensures performance and durability under challenging conditions.

Operates with 12 contacts arranged in 2 rows for efficient wiring. Maintains IP67 rating for high resistance against dust and water ingress. Supports a current rating of 13A suitable for automotive applications. Constructed with fibreglass reinforced polybutylene terephthalate housing for durability.

Designed to operate between -40°C and 125°C to withstand automotive thermal conditions. Secures mounting via a clip mechanism for stable installation. Incorporates colour coding and physical keying to prevent mismatching.

Suitable for wire diameter range from 2.18 to 3.67 mm with standard diameter wire seals. Compliant with EU RoHS and EU ELV environmental standards. Compact dimensions of 37.6mm width, 26.65mm height, and 47.55mm depth for integration flexibility.
