TE Connectivity Mini-Universal MATE-N-LOK II Series Female Crimp Terminal 3A 20-16 AWG 794223-1
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Current | 3A |
| Length | 19.94mm |
| Model | 794223-1 |
| Gender | Female |
| Contact Material | Brass |
| Series | Mini-Universal MATE-N-LOK II |
| Termination Type | Crimp |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -30°C |
| For Use With | Mini-Universal MATE-N-LOK II Connector Housing |
| Contact Plating | Tin |
| Minimum Wire Size mm² | 0.5mm² |
| Maximum Wire Size mm² | 1.4mm² |
| Minimum Wire Size AWG | 20AWG |
| Maximum Wire Size AWG | 16AWG |
| Maximum Contact Resistance | 20mΩ |
Key Features
- This crimp terminal uses brass contact material with tin plating for reliable connectivity.
- It is optimized for use with Mini-Universal MATE-N-LOK II connector housings.
- Suitable for operating temperatures ranging from -30°C up to 105°C.
- The maximum contact resistance is 20 milliohms ensuring efficient conductivity.
- Termination is via crimping to provide a secure and durable connection.
- The terminal length is 19.94 mm to fit precise connector assemblies.
- Designed for female contact application in electronic and electrical connector systems.
Product Description
TE Connectivity 794223-1 Mini-Universal MATE-N-LOK II Series Female Crimp Terminal supports reliable electrical connections in electronics and power applications. Rated for a continuous current of 3 amps, this terminal is compatible with wire sizes from 20 AWG (0.5 mm²) minimum to 16 AWG (1.4 mm²) maximum, making it suitable for moderate power signaling and control circuits.
The crimp terminal employs brass as the contact material, plated with tin to resist corrosion and ensure electrical integrity over time. It is designed for crimp termination which allows for secure and consistent mechanical and electrical performance within Mini-Universal MATE-N-LOK II connector housings.
The terminal can operate reliably in environments with temperatures ranging from -30°C to 105°C, suitable for many industrial, automotive, and electronic applications. The contact length of approximately 19.94 mm ensures a precise fit within connector systems.
With a maximum contact resistance capped at 20 milliohms, this Crimp Terminal reduces leakage and signal loss, enhancing system performance and electrical safety. It is ideal for use in manufacturing, telecommunications, instrumentation, and other industrial sectors requiring durable and maintainable cable-to-board connections.
Brass contact material with tin plating for corrosion resistance. Compatible with Mini-Universal MATE-N-LOK II connector housings. Crimp termination for secure connections. Wide operating temperature range for diverse applications.
Supports wire gauges from 20 AWG to 16 AWG. 3A continuous current rating. Length of 19.94 mm for precise assembly.
This product is an essential component in electrical connectors for industrial and electronic manufacturing. Browse the Electronics Connectors category on EnvMart for compatible connectors and assembly tools from TE Connectivity and other trusted brands.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous current rating for this crimp terminal is 3A.
This terminal is compatible with wire sizes ranging from 20 AWG (0.5 mm²) to 16 AWG (1.4 mm²).
It can operate reliably in temperatures ranging from -30°C to 105°C.
The contact material for this terminal is brass, which is plated with tin to enhance corrosion resistance.
The length of this crimp terminal is approximately 19.94 mm.
This terminal uses crimp termination to provide a secure and durable connection.
It is optimized for use with Mini-Universal MATE-N-LOK II connector housings.
The maximum contact resistance is 20 milliohms, which helps reduce signal loss.
This crimp terminal is manufactured in India.
This terminal is suitable for applications in manufacturing, telecommunications, instrumentation, and other industrial sectors requiring reliable cable-to-board connections.
This crimp terminal belongs to the Mini-Universal MATE-N-LOK II series.
This crimp terminal is designed for female contact applications.
