TE Connectivity Multi-Interlock Mark II Automotive Connector Male Natural Through Hole 5 Way Solder Termination 172037-1
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Colour | Natural |
| Current | 10A |
| Height | 22mm |
| Model | 172037-1 |
| Depth | 16.7mm |
| Width | 23.6mm |
| Gender | Male |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | Multi-Interlock Mark II |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | Shrouded Header |
| Minimum Operating Temperature | -65°C |
| Number of Rows | 2 |
| Standards/Approvals | RoHS |
| Contact Plating | Tin |
| Number of Contacts | 5 |
Key Features
- This connector features a natural color nylon housing for sturdy construction.
- It includes 5 brass contacts plated with tin to ensure corrosion resistance.
- The connector supports a current rating of 10 amps for robust electrical flow.
- Its shrouded header sub-type and through hole mount type enable secure PCB installation.
- Operating temperature ranges from -65°C to 105°C, suitable for demanding environments.
- The connector has 2 rows of contacts with 6mm row spacing for compact design.
- Contact termination is by solder, providing strong and permanent electrical connection.
- Compact dimensions of 23.6mm width, 22mm height, and 16.7mm depth make it suitable for tight spaces.
Product Description
TE Connectivity 172037-1 Multi-Interlock Mark II Automotive Connector Male Natural Through Hole 5 Way Solder Termination is a high-quality shrouded header connector engineered for automotive electrical systems requiring dependable performance and durability.
This connector features a nylon housing with a natural finish, known for its excellent insulation and mechanical strength. The brass contact material together with tin plating ensures optimal conductivity and corrosion resistance, suitable for automotive environments.
With a current rating of 10A and two rows of five contacts each, spaced at 6mm, it provides secure, reliable electrical connections on PCBs via through-hole solder termination. The connector can withstand operating temperatures from -65°C up to 105°C, making it fit for use in harsh automotive conditions including engine compartments and vehicle interiors.
Its compact physical dimensions (23.6 mm width, 22 mm height, 16.7 mm depth) enable integration into space-constrained assemblies while maintaining robust electrical capacity. This connector supports male gender contacts suitable for automotive connections.
The Multi-Interlock Mark II series assures secure coupling to mating components with good environmental sealing. Its compliance with RoHS confirms adherence to environmental and safety norms. The solder termination provides a permanent and high integrity electrical joint, preferred for vibration-prone automotive applications.
The mechanical design with shrouded header and through-hole mount type facilitates easy PCB integration and assembly. Suitable for industrial, automotive electrical, manufacturing, and vehicle repair and retrofit uses.
Overall, the TE Connectivity 172037-1 connector provides dependable electrical performance combined with mechanical robustness tailored for automotive electronics engineers and technicians.
Explore additional models and accessories in the Automotive Connector section at EnvMart to meet diverse automotive electrical connection needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector supports a current rating of 10 amps, allowing for robust electrical flow in automotive applications.
This model has compact dimensions of 23.6 mm in width, 22 mm in height, and 16.7 mm in depth, making it suitable for tight spaces.
It can operate within a temperature range of -65°C to 105°C, making it suitable for demanding automotive environments.
The connector features solder termination, providing a strong and permanent electrical connection.
This model includes 5 contacts arranged in 2 rows, with a spacing of 6 mm between the rows.
The housing is made from nylon, which provides good insulation and mechanical strength.
Yes, it is compliant with RoHS standards, ensuring adherence to environmental and safety norms.
The contacts are made of brass and are plated with tin to ensure corrosion resistance.
It supports a through-hole mount type, which facilitates secure PCB installation.
This connector features male gender contacts, suitable for automotive connections.
It belongs to the Multi-Interlock Mark II series, designed for secure coupling to mating components.
The connector is manufactured in India, indicating its origin.
