Vishay Single Layer Ceramic Capacitor 470 pF 1kV dc ±10 % S3N Dielectric, F Series, Through Hole, Radial F471K25S3NN63J5R

Free Delivery in India | Lowest Global Shipping Charges

Vishay Single Layer Ceramic Capacitor 470 pF 1kV dc ±10 % S3N Dielectric, F Series, Through Hole, Radial F471K25S3NN63J5R

Name: Vishay Single Layer Ceramic Capacitor 470 pF 1kV dc ±10 % S3N Dielectric, F Series, Through Hole, Radial F471K25S3NN63J5R
Brand: Vishay
SKU: 219563
Price: 0.11 USD
Availability: InStock



Category Single Layer Ceramic Capacitors Brand Vishay Condition New

Specifications

Country of Origin	India
Voltage	1kV dc
Diameter	6.5mm
Brand	Vishay
Height	40mm
Model	F471K25S3NN63J5R
Width	18mm
Mount Type	Through Hole
Series	F
Maximum Operating Temperature	125°C
Tolerance	±10 %
Capacitance	470pF
Minimum Operating Temperature	-30°C
Terminal type	Radial
Dissipation Factor	0.2%
Standards/Approvals	EC, RoHS
Package/Case	Disc
Pin Count	2
Dielectric	S3N
Suppression Class	Class I

Key Features

Constructed with S3N ceramic dielectric for high frequency and high voltage applications.
Designed for through hole mounting with radial terminals for easy PCB insertion.
Rated for maximum operating temperature of 125°C ensuring stability in harsh environments.
Features low dissipation factor of 0.2% and Class I suppression for minimal signal loss.
Suitable for use in SMPS, HF ballast, snubber circuits and other high voltage applications.
Disc packaging with 2-pin count and epoxy-resin flame resistant encapsulation for safety.
Complies with EC and RoHS standards ensuring environmental compliance.

Product Description

Vishay F471K25S3NN63J5R is a high-reliability single layer ceramic capacitor featuring a capacitance of 470 pF and voltage rating of 1kV dc with ±10% tolerance. It utilizes an S3N dielectric ceramic material, making it an excellent choice for circuits requiring high capacitance in a compact form factor.

The capacitor is designed for through hole mounting and comes with radial tinned copper leads of 0.6 or 0.8 mm diameter, kinked for stability and spaced at 5 mm, 7.5 mm or 10 mm, offering flexible PCB installation options. Its disc shape and epoxy resin encapsulation provide flame resistance compliant with UL 94 V-0 standards, suitable for demanding industrial and commercial electronic applications.

This product boasts a maximum operating temperature of 125°C, a low dissipation factor of 0.2%, and Class I suppression class, indicating minimal energy loss and high performance at high frequencies. It meets IEC 60384-9 and EIA 198 standards and is RoHS compliant, highlighting its safety and environmental suitability.

Applicable in switched-mode power supplies (SMPS), high frequency ballasts, snubber circuits, and other high voltage electronic assemblies, this capacitor offers consistent and durable operation in industrial, laboratory, manufacturing, and power electronics contexts.

Constructed with silver-plated ceramic disc and tinned copper leads for optimal conductivity and durability. Flame resistant epoxy encapsulation enhances product safety in electronic designs. Compliant with EC and RoHS directives for environmental and electrical safety.

Designed for a wide temperature range from -30°C to 125°C to endure harsh environments. Pin count of 2 with radial terminal configuration ensures secure mounting and connection.

This Vishay capacitor is an ideal component for engineers and technicians seeking reliable, high-voltage ceramic capacitors for critical electronic circuit applications. Browse our comprehensive catalog of capacitors and electronic components at EnvMart to find compatible parts and accessories.
