Vishay Single Layer Ceramic Capacitor 180 pF 3kV dc ±10 % S3N Dielectric Through Hole, F Series, Radial F181K29S3NR63K7R

Free Delivery in India | Lowest Global Shipping Charges

Vishay Single Layer Ceramic Capacitor 180 pF 3kV dc ±10 % S3N Dielectric Through Hole, F Series, Radial F181K29S3NR63K7R

Name: Vishay Single Layer Ceramic Capacitor 180 pF 3kV dc ±10 % S3N Dielectric Through Hole, F Series, Radial F181K29S3NR63K7R
Brand: Vishay
SKU: 219559
Price: 0.1 USD
Availability: InStock



Category Single Layer Ceramic Capacitors Brand Vishay Condition New

Specifications

Country of Origin	India
Voltage	3kV dc
Diameter	7.5mm
Brand	Vishay
Height	40mm
Model	F181K29S3NR63K7R
Width	18mm
Mount Type	Through Hole
Series	F
Maximum Operating Temperature	125°C
Tolerance	±10 %
Capacitance	180pF
Minimum Operating Temperature	-30°C
Terminal type	Radial
Dissipation Factor	0.2%
Standards/Approvals	RoHS, EC
Package/Case	Disc
Pin Count	2
Dielectric	S3N
Suppression Class	Class I

Key Features

Uses Class 1 S3N dielectric material for improved reliability.
F Series design with radial terminal and through-hole mount type.
Offers ±10 % capacitance tolerance suitable for precision applications.
Maximum operating temperature rating of 125 °C for high temperature stability.
Constructed with silver-plated ceramic disc and epoxy resin encapsulation.
Low dissipation factor of 0.2% ensures minimal power loss in circuits.
Designed for use in SMPS, high frequency ballast, and snubber circuits.
Complies with IEC 60384-9, RoHS, and EC standards for quality and safety.

Product Description

Vishay F181K29S3NR63K7R is a high reliability single layer ceramic capacitor featuring a capacitance of 180 pF and rated voltage of 3kV dc. Constructed using a ceramic disc with silver-plated surfaces and kinked tinned copper leads, it offers superior performance for demanding electronic applications.

This capacitor belongs to the F Series and is mounted through-hole with radial terminals. Its Class 1 S3N dielectric material enables stability and low losses, making it ideal for high frequency switching power supplies, ballast circuits, and snubber circuits where precision and durability are essential.

The product withstands maximum operating temperatures up to 125 °C and maintains low dissipation factor of 0.2%, ensuring efficiency and stability under thermal stress. The epoxy resin encapsulation meets UL 94 V-0 flammability standards, ensuring safe operation.

Typical applications include power electronics, industrial electronic equipment, and other circuits requiring high voltage capacitors with tight tolerance and stable capacitance. Its compact dimensions with 7.5 mm diameter, 18 mm width, and 40 mm height facilitate easy integration in electronic assemblies.

Uses Class 1 S3N dielectric for superior performance and reliability. Features ±10 % tolerance for accurate capacitance specification. Constructed with silver-plated ceramic disc and kinked tinned copper leads. Epoxy resin encapsulation with UL 94 V-0 flammability rating.

Compliant with IEC 60384-9, RoHS, and EC standards. High voltage rating of 3kV dc suitable for snubber and ballast circuits. Designed for through-hole mounting with radial terminals. Maximum operating temperature 125 °C for reliable high temperature operation.

This Vishay capacitor is suitable for industrial, manufacturing, electronics assembly, and repair operations, providing a robust solution for high voltage ceramic capacitor needs. Explore the full range of capacitors and electronic components at EnvMart for your next project.
