TE Connectivity Metrimate Female Connector Housing 25 Contacts 5.08 mm Pitch 5 Row Straight 211149-1
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Orientation | Straight |
| Length | 62.53mm |
| Model | 211149-1 |
| Width | 30.78mm |
| Mount Type | Panel |
| Housing Material | Polyethylene Terephthalate |
| Series | Metrimate |
| Number of Rows | 5 |
| Pitch | 5.08mm |
| For Use With | PCB Connector |
| Number of Contacts | 25 |
| Connector Gender | Female |
Key Features
- The housing features a durable Polyethylene Terephthalate construction ensuring electrical insulation.
- Designed for panel mount applications with a length of 62.53 mm and width of 30.78 mm.
- Compatible for use with PCB connectors to enable reliable wire-to-board connections.
- Metrimate series provides higher pinout density than the Mate-N-Lok range for versatile design options.
- Connector offers blind mating capability with guide pins for up to 2.3 mm misalignment tolerance.
- Complies with no specific standards or approvals but meets industry performance expectations.
- Ideal for electronics, power distribution, and industrial control equipment requiring secure female connectors.
- Straight orientation eases installation and alignment on PCB panels.
Product Description
TE Connectivity 211149-1 Metrimate Female Connector Housing is a precision-engineered connector housing designed for electronic and power applications. Featuring 25 contacts arranged in 5 rows with a 5.08 mm pitch, this housing accommodates high-density wire-to-board connections suitable for industrial, HVAC, manufacturing, and automation equipment.
The housing is made from black Polyethylene Terephthalate thermoplastic with UL 94V-0 flammability rating, ensuring mechanical robustness and electrical insulation for demanding environments. The straight connector orientation supports easy panel mounting and installation, with dimensions measuring 62.53 mm in length and 30.78 mm in width.
Its Metrimate series design offers higher pinout density than the Mate-N-Lok range, enabling more compact wiring solutions. The housing also provides 'blind' mating capabilities with molded guide pins to accommodate up to 2.3 mm misalignment, simplifying assembly and maintenance.
This female connector housing is intended for use with PCB connectors in power distribution systems, industrial controls, automation devices, and electronic equipment requiring reliable, multi-contact connections.
The housing material is Polyethylene Terephthalate, offering excellent durability and insulation. 25 contacts arranged across 5 rows allow high wiring connectivity. 5.08 mm pitch ensures compatibility with standard PCB connector layouts.
Panel mount type is designed for secure installation in equipment panels. Straight orientation aids in efficient connection alignment. Robust design supports industrial and manufacturing applications. Metrimate series ensures compatibility with related connector components.
Dimensions (LxW): 62.53 mm x 30.78 mm.
Set yourself up for successful component integration in industrial, electronics manufacturing, and control system projects with this TE Connectivity Metrimate female Connector Housing. Explore our full range of connectors and housings for compatible solutions on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector housing has a pitch of 5.08 mm, which ensures compatibility with standard PCB connector layouts.
This model features 25 contacts arranged in 5 rows, allowing for high-density wire-to-board connections.
The dimensions of this housing are 62.53 mm in length and 30.78 mm in width, making it suitable for panel mount applications.
The housing is constructed from Polyethylene Terephthalate, which provides electrical insulation and mechanical robustness.
The connector housing features a straight orientation, which facilitates easy installation and alignment on PCB panels.
This model is designed for panel mount applications, ensuring secure installation in equipment panels.
This connector housing offers blind mating capability with guide pins that accommodate up to 2.3 mm of misalignment.
It is intended for use in power distribution systems, industrial controls, automation devices, and electronic equipment requiring reliable multi-contact connections.
While it does not comply with specific standards or approvals, it meets industry performance expectations for its intended applications.
This housing is part of the Metrimate series, which offers higher pinout density compared to the Mate-N-Lok range.
Yes, it is specifically designed for use with PCB connectors, enabling reliable wire-to-board connections.
The country of origin for this connector housing is India.
