Preci-Dip 811 Series Straight Surface Spring Loaded Connector, 3 Contacts, 2.54 mm Pitch, 1 Row 811-SS-003-30-008191

Preci-Dip 811-SS-003-30-008191 Spring Loaded Connector is a high-quality electronic connector designed for surface mounting on PCBs. It features 3 brass contacts gold plated to ensure excellent electrical conductivity with low resistance and corrosion resistance. The 2.54 mm pitch with a single row and straight orientation allows precise and stable connections.

The connector's shrouded design protects the contacts during use and handling, enhancing reliability in demanding environments. It is made from fibreglass reinforced polyethylene terephthalate housing, providing mechanical strength and temperature resilience.

Operating temperature ranges from -55°C to 125°C, making it suitable for harsh industrial and electronic applications. Rated for 150V and 3.5A current, it is suitable for a wide range of low voltage electronic devices that require robust spring-loaded connection points.

Spring-loaded contacts provide stable multipoint electrical connectivity, preventing micro-discontinuities caused by vibration or movement, assuring consistent performance across varying operational conditions.

This connector contains 3 spring-loaded contacts with gold-plated brass material. It is constructed with a fibreglass reinforced PET housing for durability and heat resistance. The mounting type is surface mount with solder termination for PCB assembly.

Designed for use in electronics manufacturing, industrial automation, and precision connections. Reliable operation in temperature extremes from -55°C up to 125°C. Offers a 2.54 mm pitch single row layout with a shrouded, straight contact orientation.

These connectors are ideal for use in various industrial, manufacturing, laboratory, and electronics applications where reliable surface mount spring-loaded connections are critical. Their design supports stable, low-resistance contact even in mobile or vibration-prone environments.
