Preci-Dip 3 Way Preci-Dip Straight Through Hole 2.54 mm Pitch SIL Socket 100 V ac, 150 V dc, Solder, 3A 801-87-003-10-001101

Free Delivery in India | Lowest Global Shipping Charges

Preci-Dip 3 Way Preci-Dip Straight Through Hole 2.54 mm Pitch SIL Socket 100 V ac, 150 V dc, Solder, 3A 801-87-003-10-001101

Name: Preci-Dip 3 Way Preci-Dip Straight Through Hole 2.54 mm Pitch SIL Socket 100 V ac, 150 V dc, Solder, 3A 801-87-003-10-001101
Brand: Preci-Dip
SKU: 215430
Price: 0.57 USD
Availability: InStock



Category SIL Socket Brand Preci-Dip Condition New

Specifications

Country of Origin	Switzerland
Voltage	100, 150V ac
Brand	Preci-Dip
Orientation	Straight
Current	3A
Length	7.62mm
Depth	7mm
Width	2.54mm
Mount Type	Through Hole
Housing Material	Fibreglass Reinforced Polycyclohexylenedimethylene Terephthalate
Contact Material	Brass, Beryllium Copper Alloy
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Pitch	2.54mm
Contact Plating	Gold, Tin
Number of Contacts	3

Key Features

Constructed with brass and beryllium copper alloy contacts for durability and conductivity.
Gold and tin plating ensure reliable contact performance and corrosion resistance.
Designed for through-hole mounting with a straight orientation.
Rated for 100 V AC and 150 V DC voltage with a current capacity of 3 amps.
Housing made from fibreglass reinforced polycyclohexylenedimethylene terephthalate for thermal and mechanical stability.
Operates reliably within temperature range of -55°C to 125°C.
Compact dimensions with 7.62 mm length, 2.54 mm width, and 7 mm depth.
Termination via solder, ensuring stable and permanent electrical connection.

Product Description

Preci-Dip 801-87-003-10-001101 3 Way Straight Through Hole SIL Socket features precision engineering and high-quality materials suited for demanding industrial and electronic applications.

This socket supports a pitch of 2.54 mm and accommodates a current of up to 3 amps at 100 V AC and 150 V DC. The contact system uses brass and beryllium copper alloy, plated with gold and tin, to provide excellent electrical conductivity and resistance to corrosion.

The housing is crafted from fibreglass reinforced polycyclohexylenedimethylene terephthalate, offering enhanced mechanical strength and thermal resistance within operating temperatures from -55°C up to 125°C. Its through-hole mount and solder termination ensure reliable installation on PCB assemblies.

Compact dimensions - length 7.62 mm, width 2.54 mm, depth 7 mm - make it suitable for space-constrained designs. Manufactured in Switzerland, it conforms to industrial standards for quality and durability.

Brass and beryllium copper alloy contact materials guarantee reliable connections. Gold and tin plating improve corrosion resistance and signal integrity. Through-hole solder termination provides robust mechanical and electrical joint.

Fibreglass reinforced polycyclohexylenedimethylene terephthalate housing resists thermal and mechanical stresses. Wide operating temperature range from -55°C to 125°C ensures environmental resilience. Supports 3 amp current and up to 150 V DC voltage for versatile electronic applications.

Compact form factor fits various industrial and commercial PCB designs. Swiss manufacturing ensures high production standards and quality control.

This Preci-Dip 3 Way SIL Socket is ideal for electronic component assemblies in industrial, commercial, and laboratory environments where precision and reliability are essential. Compatible with standard PCBs requiring 2.54 mm pitch connections, it supports seamless integration into diverse electrical systems.
