Preci-Dip 813 Series Straight Through Hole Spring Loaded Connector 24 Contacts 2.54 mm Pitch 2 Row 813-S1-024-10-014101

Preci-Dip 813-S1-024-10-014101 is a spring loaded connector from the 813 Series, featuring 24 spring loaded contacts arranged in 2 rows with 2.54 mm pitch. Designed for through hole mounting on PCBs, it offers a shrouded configuration for enhanced mechanical protection. The connector housing is manufactured from fibreglass reinforced polyethylene terephthalate, ensuring durability in demanding environments.

Each contact is made of brass with gold plating, which helps to maintain low and stable electrical resistance, even during motion or vibration. The spring-loaded mechanism guarantees reliable multipoint electrical connections without micro-discontinuities, which is critical for industrial, laboratory, manufacturing, and electronic assembly applications.

This connector supports a current rating of 3.5 A and operates at voltages up to 150 V. Its operating temperature ranges from -55°C to 125°C with a row pitch of 2.54 mm matching standard PCB header dimensions. The shrouded design aids in precise alignment and protects contacts from damage during assembly and use.

Preci-Dip connectors are excellent alternatives to conventional connectors, delivering long-lasting, reliable electrical performance in a variety of sectors including industrial equipment, test instrumentation, and electronics manufacturing.

The set contains a single connector unit with specifications suited for high-reliability electronic assembly and repair. Features spring-loaded contacts ensuring low electrical resistance and high reliability. Mount type is through hole for secure PCB integration.

Contact material is brass with gold plating for improved conductivity and corrosion resistance. Operating temperature range from -55°C to 125°C for robust performance. Supports a current rating of 3.5 A and a voltage of 150 V.

Housing made of fibreglass reinforced polyethylene terephthalate for durability. Shrouded design provides added mechanical protection and alignment. Suitable for industrial and electronic applications requiring stable multipoint connections.
