Preci-Dip 811 Series Straight Through Hole Spring Loaded Connector, 7 Contact(s), 2.54 mm Pitch, 1 Row 811-S1-007-10-015101

Free Delivery in India | Lowest Global Shipping Charges

Preci-Dip 811 Series Straight Through Hole Spring Loaded Connector, 7 Contact(s), 2.54 mm Pitch, 1 Row 811-S1-007-10-015101

Name: Preci-Dip 811 Series Straight Through Hole Spring Loaded Connector, 7 Contact(s), 2.54 mm Pitch, 1 Row 811-S1-007-10-015101
Brand: Preci-Dip
SKU: 215256
Price: 7.86 USD
Availability: InStock



Category Connector Brand Preci-Dip Condition New

Specifications

Country of Origin	Switzerland
Voltage	150V
Brand	Preci-Dip
Orientation	Straight
Current	3.5A
Model	811-S1-007-10-015101
Mount Type	Through Hole
Housing Material	Fibreglass Reinforced Polyethylene Terephthalate
Contact Material	Brass
Series	811
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	7
Contact Gender	Male
Shrouded/Unshrouded	Shrouded

Key Features

Features 7 gold-plated brass contacts for enhanced conductivity.
2.54 mm pitch and 1 row orientation suit compact PCB mounting.
Fibreglass reinforced polyethylene terephthalate housing ensures durability.
Through hole mount type provides secure PCB integration.
Operating temperature range from -55°C to 125°C for broad environmental compatibility.
Supports a voltage rating of 150V and current up to 3.5A maximum.
Male contact gender with solder termination for reliable electrical contact.
Shrouded connector design minimizes accidental contact and improves safety.

Product Description

Preci-Dip 811-S1-007-10-015101 Spring Loaded Connector is a high-quality, precision engineered component designed for reliable electronic connections on printed circuit boards. It offers 7 gold-plated brass contacts arranged in a single row with a 2.54 mm pitch, making it suitable for compact and high-density PCB layouts.

The housing is made from fibreglass reinforced polyethylene terephthalate, providing mechanical strength and resistance to environmental factors. The connector uses a through hole mount type, ensuring robust and secure installation on PCBs. Its straight orientation and shrouded design enhance safety by preventing accidental contact and shielding the contacts.

This connector operates reliably across a wide temperature range from -55°C to 125°C, and supports an electrical rating of up to 150V and 3.5A current, making it suitable for various industrial, electronics manufacturing, and test equipment applications.

The spring-loaded contact design maintains consistent electrical resistance despite mechanical vibrations or movement, assuring stable signal integrity and performance. The male contact with solder termination securely connects with counterpart components, facilitating dependable connections in demanding environments.

7 gold-plated brass spring-loaded contacts for low resistance and durability. 2.54 mm pitch and single row spacing for dense PCB connections. Fibreglass reinforced polyethylene terephthalate housing with UL 94V-0 fire rating.

Through hole mounting ensures mechanical stability in PCBs. Wide operating temperature range (-55°C to 125°C) for industrial use. Voltage rating up to 150V and current capacity of 3.5A. Shrouded design enhances safety and reliability.

Male solder termination contact type for secure electrical connections.

Ideal for industrial electronics, manufacturing, testing, and instrumentation requiring reliable spring-loaded PCB connectors. Made in Switzerland, this connector combines precision, durability, and performance for demanding applications. Explore more Connectors and electronic components on EnvMart to meet your design and production needs.
