Preci-Dip 2 Way Right Angle Through Hole 2.54 mm Pitch SIL Socket 100 V AC, 150 V DC, Solder 801-87-002-20-002101

Preci-Dip 801-87-002-20-002101 SIL Socket is a high-quality electronic component designed as a 2-way right angle through hole socket with a 2.54 mm pitch. It supports 100 V AC and 150 V DC voltage with a current rating of 3A, making it suitable for a wide range of PCB applications requiring secure and precise electrical connections.

The socket features contacts made from a Beryllium Copper Alloy and Brass for high conductivity and mechanical strength. Contact surfaces are plated with Tin and Gold to ensure durability and excellent corrosion resistance. The socket housing is fabricated from Fibreglass Reinforced Polycyclohexylenedimethylene Terephthalate, providing robust mechanical support and stability under demanding conditions.

Its right angle orientation is designed for through hole mounting, facilitating PCB component assembly and solder termination. The socket performs reliably over a temperature range from -55°C to 125°C, ensuring suitability for industrial grade electronics and harsh environments.

With compact dimensions of length 5.08 mm, width 2.95 mm, and depth 2.54 mm, this socket fits neatly on PCBs with standard 2.54 mm pitch spacing. It is especially ideal for industrial electronics, laboratory instrumentation, telecommunications equipment, and other precision electronic assembly requiring dependable and consistent performance.

Features 2 contacts with 2.54 mm pitch for precise connectivity. Constructed with Beryllium Copper Alloy and Brass for excellent conductivity. Contact plating combines Tin and Gold for durability and corrosion resistance.

Right angle orientation suitable for through hole mounting configurations. Housing made of Fibreglass Reinforced Polycyclohexylenedimethylene Terephthalate offering strength and stability. Operates reliably between -55°C and 125°C temperature range.

Compact 5.08 mm length, 2.95 mm width, and 2.54 mm depth for efficient PCB design. Suited for industrial, laboratory, telecommunications, and manufacturing applications.

This Preci-Dip SIL Socket 801-87-002-20-002101 is manufactured in Switzerland, incorporating stringent quality standards. It represents a reliable choice for engineers and technicians requiring high performance and stable electrical sockets. Explore more in electronic components and SIL Sockets with EnvMart for industrial and commercial needs.
