Amphenol Communications Solutions High Density 15 Way Right Angle Through Hole D-Sub Connector 250V 3A L717HD
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 250V |
| Brand | Amphenol Communications Solutions |
| Orientation | Right Angle |
| Current | 3A |
| Model | L717HD |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Contact Material | Brass |
| Series | L717HD |
| Mounting Hardware | 4 to 40 UNC Screw Lock |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Contact Plating | Gold |
| Number of Contacts | 15 |
| Contact Gender | Male |
| Connector Gender | Male |
| Connector Type D | D-Sub |
| D-Sub Shell Size | DE-15 |
Key Features
- Features a high-density 15 way configuration for compact design.
- Utilizes a right angle orientation suitable for PCB mounting.
- Mount type is through hole with 4 to 40 UNC screw lock for secure fastening.
- Contact material is brass with gold plating for superior conductivity and corrosion resistance.
- Housing is made of thermoplastic ensuring durability and insulation.
- Designed for a voltage rating of 250V and current capacity of 3A.
- Operating temperature ranges from -55°C minimum to 105°C maximum for harsh environments.
- Termination type is solder, providing robust electrical contact.
Product Description
Amphenol Communications Solutions L717HD is a high-density 15 way right angle through hole D-Sub connector designed for reliable and durable electrical connections in industrial, electronic, and manufacturing applications. Rated for 250V and 3A current, it integrates seamlessly with PCB assemblies requiring a compact and secure connector solution.
This connector features brass contacts plated with gold to ensure excellent conductivity and resistance to corrosion. The housing is constructed from thermoplastic material providing electrical insulation and mechanical strength.
Its right angle orientation allows for space-saving mounting, and the through hole mount type ensures secure fixation, enhanced by 4 to 40 UNC screw locks for mounting hardware stability. It is intended for use in environments ranging from -55°C to 105°C, making it suitable for a wide range of operating conditions.
The DE-15 shell sized connector has a male gender configuration and is terminated via soldering techniques for robust electrical connections. There are no specific standards or approvals associated with this product, reflecting its general-purpose industrial design.
Features a high-density 15 way configuration for compact design. Utilizes a right angle orientation suitable for PCB mounting. Mount type is through hole with 4 to 40 UNC screw lock for secure fastening. Contact material is brass with gold plating for superior conductivity and corrosion resistance.
Housing is made of thermoplastic ensuring durability and insulation. Designed for a voltage rating of 250V and current capacity of 3A. Operating temperature ranges from -55°C minimum to 105°C maximum for harsh environments.
Termination type is solder, providing robust electrical contact. Connector gender is male with a DE-15 shell size. Manufactured in China as per the L717HD series specifications.
This D-Sub Connector is ideally suited for electronics, industrial automation, power supply connections, computer hardware interfaces, and electronic test equipment where reliable signal and power transmission is critical. Browse our Electronics & Electricals category for other connector solutions by Amphenol Communications Solutions at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a voltage of 250V and a current capacity of 3A.
It features a right angle orientation and utilizes a through hole mount type with 4 to 40 UNC screw locks for secure fastening.
The housing is made of thermoplastic, while the contacts are constructed from brass and plated with gold for enhanced conductivity and corrosion resistance.
It operates within a temperature range of -55°C to 105°C, making it suitable for harsh environments.
This connector has a total of 15 contacts, configured in a high-density layout.
The termination type is solder, providing robust electrical contact.
The connector gender is male, and it is designed with a DE-15 shell size.
It is suitable for electronics, industrial automation, power supply connections, computer hardware interfaces, and electronic test equipment.
The gold plating on the brass contacts ensures superior conductivity and resistance to corrosion, enhancing the connector's performance.
There are no specific standards or approvals associated with this product, indicating its general-purpose industrial design.
This connector is manufactured in China as per the L717HD series specifications.
It is compatible with 4 to 40 UNC screw locks for secure mounting.
