Souriau Sunbank by Eaton MIL Spec Circular Connector 4 Contacts 7.5A Panel Mount Straight Brown Copper Alloy 85107A84P50

Free Delivery in India | Lowest Global Shipping Charges

Souriau Sunbank by Eaton MIL Spec Circular Connector 4 Contacts 7.5A Panel Mount Straight Brown Copper Alloy 85107A84P50

Name: Souriau Sunbank by Eaton MIL Spec Circular Connector 4 Contacts 7.5A Panel Mount Straight Brown Copper Alloy 85107A84P50
Brand: Souriau Sunbank by Eaton
SKU: 211989
Price: 35.3 USD
Availability: InStock



Category Mil Spec Circular Connector Brand Souriau Sunbank by Eaton Condition New

Specifications

Country of Origin	France
Brand	Souriau Sunbank by Eaton
Colour	Brown
Orientation	Straight
Current	7.5A
Model	85107A84P50
Mount Type	Panel Mount
Contact Material	Copper Alloy
Series	851
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Contact Plating	Gold
Number of Contacts	4
Contact Gender	Male
Connector Gender	Female
Shell Size	8
Military Standard	MIL-DTL-26482
Mating Type	Bayonet
Shell Plating	Olive Drab Cadmium

Key Features

The connector features a positive bayonet coupling mechanism for secure connection.
Designed for panel mount applications with a straight orientation.
Shell size 8 with olive drab cadmium plating ensures durability.
Contact material is copper alloy with gold plating for reliable conductivity.
Meets MIL-DTL-26482 military standard for robust performance.
Operating temperature ranges from -55°C to 125°C.
Termination is solder type for secure electrical connections.
Connector gender is female and contact gender is male.

Product Description

Souriau Sunbank by Eaton 85107A84P50 MIL Spec Circular Connector is a high-reliability 4 contact circular connector designed for demanding electrical applications.

The connector is a panel mount type featuring a straight orientation and a shell size of 8. It is constructed with copper alloy contacts plated in gold and an olive drab cadmium plated shell, ensuring robust mechanical and electrical performance suitable for harsh environments.

Rated for a current of 7.5 amps, this connector operates reliably within a temperature range of -55°C to 125°C, compliant with MIL-DTL-26482 military standards. Its bayonet mating system with a positive coupling mechanism provides fast and secure connection, reducing mating errors by employing a helical locking ring and multiple keys for proper orientation and locking engagement.

This connector is typically used in military, aerospace, industrial machinery, and high-reliability electronic equipment requiring secure and durable electrical connections under challenging conditions.

The termination type is solder, providing a solid and durable electrical connection to cables or wiring harnesses. The bayonet coupling mechanism ensures quick and reliable mechanical and electrical contacts. Panel mount design simplifies integration into control panels and enclosures.

Gold-plated copper alloy contacts optimize conductivity and corrosion resistance. The robust shell plating and construction ensure resistance to environmental factors. Compatibility with MIL-DTL-26482 standard connects the product to broad applications in defense and industry.

Temperature tolerance supports use in both extreme cold and heat environments. Gender configurations allow for versatile mating options. Standardized size 8 shell permits interchangeability within connector systems.

Available for immediate integration in industrial, aerospace, military, and electronic manufacturing sectors. Explore the category for more specialized Mil Spec Circular Connectors from Souriau Sunbank by Eaton at EnvMart.
