Souriau Sunbank by Eaton MIL Spec Circular Connector Copper Alloy Straight 26 Way Cable Male Contacts Shell 85106EC1626P50

Free Delivery in India | Lowest Global Shipping Charges

Souriau Sunbank by Eaton MIL Spec Circular Connector Copper Alloy Straight 26 Way Cable Male Contacts Shell 85106EC1626P50

Name: Souriau Sunbank by Eaton MIL Spec Circular Connector Copper Alloy Straight 26 Way Cable Male Contacts Shell 85106EC1626P50
Brand: Souriau
SKU: 211987
Price: 115.92 USD
Availability: InStock



Category Mil Spec Circular Connector Brand Souriau Condition New

Specifications

Country of Origin	France
Brand	Souriau
Orientation	Straight
Current	7.5A
Model	85106EC1626P50
Mount Type	Cable
Contact Material	Copper Alloy
Series	851
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Contact Plating	Gold
Number of Contacts	26
Contact Gender	Male
Connector Gender	Male
Shell Size	16
Military Standard	MIL-DTL-26482
Mating Type	Bayonet
Shell Plating	Olive Drab Cadmium

Key Features

Featuring bayonet coupling for secure and rapid locking.
Rated for 7.5A current with gold-plated copper alloy contacts.
Operates reliably from -55°C to 125°C temperature range.
Compliant with MIL-DTL-26482 military standard.
Olive drab cadmium plating on shell for corrosion resistance.
Termination type is solder for durable electrical connections.
Designed and manufactured in France for high quality assurance.
Series 851 connector with positive keying to ensure correct orientation.

Product Description

Souriau Sunbank by Eaton 85106EC1626P50 MIL Spec Circular Connector is a high-quality cable mount connector featuring a copper alloy straight shell and 26 male contacts designed for demanding military and industrial applications.

This MIL-DTL-26482 compliant connector employs a positive bayonet coupling mechanism with a helical locking ring that ensures rapid and secure mating. The series 851 connectors have a system of five raised keys on the plug and corresponding slots on the receptacle, guaranteeing correct orientation and location.

Constructed with a copper alloy contact material plated in gold, these connectors provide excellent electrical performance and durability. The olive drab cadmium plated shell enhances resistance to corrosion in harsh environments.

The connector supports a maximum current of 7.5A and operates efficiently within a temperature range from -55°C to 125°C. Termination is by solder type, delivering a reliable electrical connection suitable for industrial, military, aerospace, and other critical electronic systems.

Manufactured in France to stringent quality standards, this connector series ensures robust mechanical and electrical integrity, ideal for use in rugged environments and complex electronic assemblies.

Bayonet coupling for reliable locking and rapid mating. Gold-plated copper alloy contacts enhance conductivity and longevity. Wide operating temperature range from -55°C to 125°C. Olive drab cadmium plated shell for corrosion resistance.

Compatible with MIL-DTL-26482 military standard specifications. Solder termination type for durable connections. Positive keying system to prevent misalignment. Designed for cable mount applications requiring 26 contacts.

This product is ideally suited for industrial, laboratory, aerospace, military, and manufacturing applications requiring secure, durable, and high-performance electrical connectivity. Explore more connectors in the Mil Spec Circular Connector category on EnvMart for tailored solutions to your technical needs.
