RS PRO Pluggable Terminal Block 5-Contact 5 mm Pitch 1 Row 300V 15A Polyamide 66 144-4083
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 300V |
| Brand | RS PRO |
| Colour | Green |
| Orientation | Straight |
| Current | 15A |
| Length | 26.2mm |
| Model | 144-4083 |
| Depth | 12mm |
| Width | 8.5mm |
| Housing Material | Polyamide 66 |
| Number of Rows | 1 |
| Pitch | 5mm |
| Number of Contacts | 5 |
| Minimum Wire Size mm² | 0.32mm² |
| Maximum Wire Size mm² | 1.6mm² |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 14AWG |
| Wire Connection Method | Screw |
| RS PRO Pluggable Terminal Block, 5-Contact, 5 mm Pitch, 1 RowBrand | RS PRO |
Key Features
- Constructed with green polyamide 66 housing providing flame retardant protection.
- Supports wire sizes from 0.32 mm² (28 AWG) up to 1.6 mm² (14 AWG).
- Rated for a current capacity of 15 amperes and voltage of 300 volts.
- Features screw-type wire connection method with captive screws for secure clamping.
- Compact dimensions measuring 26.2 mm length, 8.5 mm width, and 12 mm depth.
- Straight orientation with professional rising clamp terminals ensuring safe and efficient wiring.
- Suited for industrial and electronic component connectivity in control panels and PCB assemblies.
Product Description
The RS PRO 144-4083 is a high-quality pluggable terminal block featuring 5 contacts arranged in a single row with a 5 mm pitch. Designed with a durable green polyamide 66 housing, it meets UL94-V0 flame retardant standards to ensure safety in electrical installations.
This terminal block supports wire sizes from 0.32 mm² (28 AWG) to 1.6 mm² (14 AWG) and is rated for a maximum current of 15A and voltage up to 300V, making it ideal for a wide range of industrial, manufacturing, and electronic equipment applications.
The screw connection method utilizes captive screws and rising clamp terminals, which guarantee secure wire fixation and reliable electrical contact. Its compact size, measuring 26.2 mm in length, 8.5 mm in width, and 12 mm in depth, allows efficient use of space in control panels and PCB assemblies.
The straight orientation and guided pin alignment simplify installation and maintenance. It is suitable for use in electronics components, power connectors, and industrial automation setups where reliable, safe electrical connections are critical.
Green polyamide 66 housing with flame retardant UL94-V0 rating. Supports solid and stranded wires between 28 and 14 AWG. Rated current of 15A and voltage of 300V for robust performance. Captive screws and rising clamp terminals provide secure wire connections.
Compact dimensions optimize panel space usage. Straight orientation with guided pin alignment ensures easy installation. Applicable in industrial, manufacturing, and electronic component assemblies.
This Pluggable Terminal Block from RS PRO is an essential component for applications requiring a reliable and safe connection solution. Explore more electronics and electrical components in EnvMart for your specific needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This terminal block is rated for a maximum current of 15 amperes and a voltage of up to 300 volts.
It supports wire sizes from 0.32 mm² (28 AWG) to 1.6 mm² (14 AWG).
The housing is made of green polyamide 66, which provides flame retardant protection.
The dimensions are 26.2 mm in length, 8.5 mm in width, and 12 mm in depth.
It features a screw-type wire connection method with captive screws for secure clamping.
The terminal block has a straight orientation with guided pin alignment for easy installation.
This model has 5 contacts arranged in a single row with a 5 mm pitch.
The country of origin for this terminal block is India.
It is suitable for industrial, manufacturing, and electronic component connectivity in control panels and PCB assemblies.
The housing meets UL94-V0 flame retardant standards, ensuring safety in electrical installations.
The pitch size of this terminal block is 5 mm.
Yes, it can accommodate both solid and stranded wires within the specified wire size range.
