HARTING SV TSDC 37 Way Straight Panel Mount D-Sub Connector with Flange Male 1kV 7.5A 09670375615

Free Delivery in India | Lowest Global Shipping Charges

HARTING SV TSDC 37 Way Straight Panel Mount D-Sub Connector with Flange Male 1kV 7.5A 09670375615

Name: HARTING SV TSDC 37 Way Straight Panel Mount D-Sub Connector with Flange Male 1kV 7.5A 09670375615
Brand: HARTING
SKU: 209069
Price: 23.49 USD
Availability: InStock



Category D-Sub Connector Brand HARTING Condition New

Specifications

Country of Origin	Germany
Voltage	1kV
Brand	HARTING
Orientation	Straight
Current	7.5A
Mount Type	Panel Mount
Housing Material	Fibreglass Reinforced Thermoplastic
Contact Material	Copper Alloy
Series	SV TSDC
Mounting Hardware	Flange
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Standards/Approvals	UL Recognised, UL 94-V0, RoHS
Contact Plating	Steel
Number of Contacts	37
Contact Gender	Male
Connector Gender	Male
Connector Type D	D-Sub

Key Features

This connector features 37 contacts allowing multiple connection points.
It supports a current rating of 7.5A for stable power transfer.
The orientation is straight with panel mount type and flange hardware for secure fixing.
Housing made from fibreglass reinforced thermoplastic ensures durability.
Suitable for operating temperatures ranging from -55°C to 125°C.
Contact material uses copper alloy with steel plating for enhanced conductivity and corrosion resistance.
Rated for voltage up to 1kV for high insulation standards.
Termination is solder type ensuring strong and stable joints.

Product Description

HARTING 09670375615 SV TSDC 37 Way Straight Panel Mount D-Sub Connector with Flange Male is an industrial-grade electronic component designed for robust and reliable electrical connections in demanding environments. Operating at a voltage of 1kV and supporting currents up to 7.5A, this connector is ideal for use in power connectors applications where durability and performance are paramount.

The connector features 37 male contacts housed in a fibreglass reinforced thermoplastic shell that provides excellent mechanical strength and resistance to environmental stress. The straight orientation and panel mount design with flange mounting hardware ensure easy installation and secure attachment to panels.

Engineered for a broad operating temperature range from -55°C to 125°C, this connector supports demanding thermal conditions in industrial, manufacturing, automation, and electronic systems. Its solder termination type enables reliable electrical connections with excellent mechanical stability. The copper alloy contacts plated with steel provide excellent conductivity and corrosion resistance, improving the connector lifespan.

This product complies with key standards including UL Recognised certification, UL 94-V0 flame retardancy, and RoHS environmental compliance, ensuring safety and regulatory adherence in various applications.

37 contacts for multiple connection points. Current rating of 7.5A for stable power delivery. Straight orientation with panel mount flange fixing. Fibreglass reinforced thermoplastic housing for durability. Wide operating temperature range from -55°C to 125°C.

Copper alloy contacts plated with steel for conductivity and corrosion resistance. Voltage rating up to 1kV meets industrial insulation requirements. Solder termination type for secure connections. Complies with UL Recognised, UL 94-V0, and RoHS standards.

This connector is well suited for industrial electronic assemblies including power distribution units, automation control systems, and manufacturing electronics. It offers a reliable and robust interface for signal and power transmission in harsh environments.

Explore more from HARTING and our comprehensive selection of D-Sub Connectors and power connectors at EnvMart.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The connector is rated for a voltage of up to 1kV, ensuring it meets high insulation standards for electrical applications.

It supports a current rating of 7.5A, allowing for stable power transfer in various applications.

This model features 37 male contacts, providing multiple connection points for enhanced connectivity.

It operates effectively within a temperature range of -55°C to 125°C, suitable for demanding environments.

The housing is made from fibreglass reinforced thermoplastic, while the contacts are copper alloy plated with steel for improved conductivity and corrosion resistance.

It utilizes a solder termination type, ensuring strong and stable electrical connections.

This model features a panel mount design with flange mounting hardware for secure installation.

It complies with UL Recognised certification, UL 94-V0 flame retardancy, and RoHS environmental compliance, ensuring safety and regulatory adherence.

The connector has a straight orientation, making it suitable for various installation scenarios.

The country of origin for this connector is Germany.

It is well-suited for industrial electronic assemblies, including power distribution units, automation control systems, and manufacturing electronics.

This model is classified as a D-Sub connector, specifically a male connector type.
