RS PRO D-Sub Connector Female 15 Way Straight 2.77 mm Pitch Through Hole 250V A-DF 15 PP/Z

Free Delivery in India | Lowest Global Shipping Charges

RS PRO D-Sub Connector Female 15 Way Straight 2.77 mm Pitch Through Hole 250V A-DF 15 PP/Z

Name: RS PRO D-Sub Connector Female 15 Way Straight 2.77 mm Pitch Through Hole 250V A-DF 15 PP/Z
Brand: RS PRO
SKU: 208245
Price: 1.18 USD
Availability: InStock



Category D-Sub Connector Brand RS PRO Condition New

Specifications

Country of Origin	China
Voltage	250V
Brand	RS PRO
Orientation	Straight
Current	3A
Model	A-DF 15 PP/Z
Mount Type	Through Hole
Housing Material	Polybutylene Terephthalate
Contact Material	Brass
Series	A-DF
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Pitch	2.77mm
Contact Plating	Gold over Nickel
Number of Contacts	15
Contact Gender	Female
Connector Gender	Female
Connector Type D	D-Sub
D-Sub Shell Size	DF-15
RS PRO 15 Way Straight 2.77 mm Pitch Through Hole D-Sub Connector FemaleBrand	RS PRO

Key Features

This D-Sub connector features 15 contacts suitable for current up to 3A.
The connector has a DF-15 shell size and operates at a voltage of 250V.
Housing is constructed from durable Polybutylene Terephthalate material.
Contacts are made of brass with gold over nickel plating to ensure reliable connectivity.
Termination type is solder, supporting stable electrical connections.
It supports operating temperatures ranging from -40°C up to 105°C.
The connector is female gender with a straight orientation suitable for a variety of electronic applications.
Ideal for industrial and electronic equipment requiring reliable D-Sub connectivity.

Product Description

ASSMANN WSW model A-DF 15 PP/Z is a high-quality D-Sub Connector with 15 female contacts arranged in a straight orientation and a pitch of 2.77 mm. Designed for through-hole PCB mounting, this connector operates at 250V and supports currents up to 3A, making it suitable for a broad range of electronic and industrial applications requiring stable, high-performance connections.

The connector features a DF-15 shell size and incorporates a robust housing made of Polybutylene Terephthalate, which provides excellent mechanical strength and electrical insulation. Its brass contacts are plated with gold over nickel, enhancing corrosion resistance and ensuring superior electrical conductivity.

The solder termination type facilitates secure attachment to PCB boards, ensuring long-lasting and reliable mechanical and electrical connections. It is rated to operate efficiently in temperature ranges from -40°C to 105°C, making it suitable for harsh environments.

This female connector is part of the A-DF series of D-Sub connectors, widely used in electronic manufacturing, telecommunications, instrumentation, and other industrial sectors. It ensures seamless signal transmission in systems requiring dependable multi-pin connector solutions.

This D-Sub connector features 15 contacts suitable for current up to 3A. The connector has a DF-15 shell size and operates at a voltage of 250V. Housing is constructed from durable Polybutylene Terephthalate material. Contacts are made of brass with gold over nickel plating to ensure reliable connectivity.

Termination type is solder, supporting stable electrical connections. It supports operating temperatures ranging from -40°C up to 105°C. The connector is female gender with a straight orientation suitable for a variety of electronic applications.

Ideal for industrial and electronic equipment requiring reliable D-Sub connectivity. Manufactured under the A-DF series, the product is made in China.

This product is ideal for industrial automation, electronic assembly, telecommunications, and other engineering applications requiring precise and durable D-Sub type connectors. Browse the Electronics & Electricals category on EnvMart to explore more D-Sub Connectors and related components.
