Amphenol Communications Solutions Bergstik Series Straight Surface Pin Header 10 Contact, 2.54 mm Pitch, 1 Row 95293-101-10LF
Specifications
| Country of Origin | France |
|---|---|
| Voltage | 1.5kV |
| Brand | Amphenol Communications Solutions |
| Orientation | Straight |
| Current | 3A |
| Model | 95293-101-10LF |
| Mount Type | Surface |
| Housing Material | Thermoplastic |
| Contact Material | Phosphor Bronze |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -65°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Mating Pin Length | 5.84mm |
Key Features
- The header supports a current rating of 3A for reliable electrical connections.
- It features a thermoplastic housing material rated UL 94 V-0 for high temperature resistance.
- Contact material is premium phosphor bronze with gold plating for enhanced conductivity and corrosion resistance.
- Suitable for board-to-board and wire-to-board connector systems with male contact gender.
- Operating temperature ranges from -65°C to 125°C, allowing for use in harsh environments.
- Mounting type is surface mount technology (SMT) for easy PCB integration.
- The mating pin length measures 5.84 mm providing secure mechanical and electrical connection.
- Designed and manufactured in France with a voltage rating up to 1.5 kV for safety compliance.
Product Description
Amphenol Communications Solutions 95293-101-10LF Bergstik Series pin header is a high-quality, unshrouded, single row, straight surface mount connector designed for advanced PCB applications. It features 10 contacts spaced at a 2.54 mm pitch, making it compatible with standard board layouts and ensuring reliable signal transmission.
The housing is constructed from high-temperature black thermoplastic with UL 94 V-0 flammability rating, offering superior durability and safety under demanding operating conditions. The contacts use phosphor bronze material with gold plating for excellent conductivity and corrosion resistance, enhancing long-term performance.
With a 3A current rating and 1.5 kV voltage rating, this pin header supports robust electrical connections in both board-to-board and wire-to-board systems. The pin length of 5.84 mm ensures secure mating, while the SMT surface mount design enables automated assembly and efficient manufacturing.
This component operates reliably in temperatures ranging from -65°C to 125°C, making it suitable for industrial, electronic manufacturing, and communication equipment applications. The product is manufactured in France and meets stringent quality standards, although it does not carry specific certifications.
The header supports a current rating of 3A for reliable electrical connections. It features a thermoplastic housing material rated UL 94 V-0 for high temperature resistance. Contact material is premium phosphor bronze with gold plating for enhanced conductivity and corrosion resistance.
Suitable for board-to-board and wire-to-board connector systems with male contact gender. Operating temperature ranges from -65°C to 125°C, allowing for use in harsh environments. Mounting type is surface mount technology (SMT) for easy PCB integration.
The mating pin length measures 5.84 mm providing secure mechanical and electrical connection. Designed and manufactured in France with a voltage rating up to 1.5 kV for safety compliance.
Ideal for electronics, communication, industrial automation, and laboratory equipment, this pin header provides durable, high-performance connectivity solutions. Explore Amphenol Communications Solutions products and similar PCB headers at EnvMart for comprehensive industrial electrical component needs.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 3A, ensuring reliable electrical connections.
It has a voltage rating of up to 1.5 kV, providing safety compliance for various applications.
The housing is made from thermoplastic rated UL 94 V-0, while the contacts are made of phosphor bronze with gold plating for enhanced conductivity and corrosion resistance.
It operates reliably in temperatures ranging from -65°C to 125°C, making it suitable for harsh environments.
This model features 10 contacts, which are spaced at a 2.54 mm pitch.
It utilizes surface mount technology (SMT), allowing for easy integration onto PCBs.
The mating pin length measures 5.84 mm, providing a secure mechanical and electrical connection.
It is designed for both board-to-board and wire-to-board connector systems with male contact gender.
The orientation of this model is straight, which is typical for many PCB applications.
This pin header is designed and manufactured in France, ensuring compliance with quality standards.
It features a solder termination type, suitable for secure connections on PCBs.
This model is unshrouded, which is common for applications requiring easy access to contacts.
