Microchip MOSFET Gate Driver 3 A Output Current 8-Pin SOIC Package 16 V TC1413NEOA

Free Delivery in India | Lowest Global Shipping Charges

Microchip MOSFET Gate Driver 3 A Output Current 8-Pin SOIC Package 16 V TC1413NEOA

Name: Microchip MOSFET Gate Driver 3 A Output Current 8-Pin SOIC Package 16 V TC1413NEOA
Brand: Microchip
SKU: 205197
Price: 1.73 USD
Availability: InStock



Category MOSFET Gate Driver Brand Microchip Condition New

Specifications

Country of Origin	India
Brand	Microchip
Height	1.42mm
Length	4.9mm
Model	TC1413NEOA
Width	3.91mm
Mount Type	Surface
Series	TC1413
Output Current	3A
Maximum Operating Temperature	85°C
Package Type	SOIC
Minimum Operating Temperature	-40°C
Number of outputs	5
Rise Time	24ns
Pin Count	8
Minimum Supply Voltage	16V
Number of Drivers	1
Fall Time	24ns
Driver Type	MOSFET

Key Features

Provides efficient MOSFET gate driving suitable for power management applications.
Features a maximum supply voltage of 16 volts ensuring versatile usage.
Single driver design with 5 output channels enhances control capability.
Compact surface mount SOIC package with dimensions of 4.9mm length and 3.91mm width.
Operates reliably within a temperature range of -40°C to 85°C.
Fast switching with 24 nanoseconds rise and fall time for improved performance.
Robust design ensuring suitability for electronic semiconductor applications.
Ideal for industrial, automotive electronics, laboratory, and power management circuit designs.

Product Description

Microchip TC1413NEOA is a MOSFET gate driver designed to provide high efficiency and reliable performance in power management and semiconductor applications. This device features a single MOSFET driver with an output current capability of 3 Amps and comes in a compact 8-pin SOIC surface mount package measuring 4.9mm in length and 3.91mm in width, with a height of 1.42mm.

Operating at a supply voltage range up to 16V, the TC1413NEOA is engineered to drive MOSFET gates smoothly and efficiently, making it highly suitable for power conversion circuits and other electronic component integrations. The device supports operation in extreme temperature conditions ranging from -40°C to 85°C, which ensures its suitability for industrial and automotive environments.

With fast switching characteristics marked by 24ns rise and fall times, this gate driver provides efficient switching performance that helps minimize energy loss and improve the overall system efficiency.

Efficient 3A output current MOSFET Gate Driver. Compact 8-pin SOIC surface mount packaging. Voltage support up to 16 volts with robust operation. Fast 24ns rise and fall switching times. Wide operating temperature range from -40°C to 85°C.

Single driver with 5 output channels for versatile control. Surface mount type for easy PCB integration. Suitable for industrial, laboratory, automotive, and power management applications.

This Microchip TC1413NEOA gate driver serves as an essential component in MOSFET and IGBT driver circuits, supporting efficient power delivery and switching applications across diverse industrial and electronic projects.
