MikroElektronika Brushless Click Motor Controller for TB6575FNG, 7-32 V DC, PWM Sensorless Controller MIKROE-2441

Free Delivery in India | Lowest Global Shipping Charges

MikroElektronika Brushless Click Motor Controller for TB6575FNG, 7-32 V DC, PWM Sensorless Controller MIKROE-2441

Name: MikroElektronika Brushless Click Motor Controller for TB6575FNG, 7-32 V DC, PWM Sensorless Controller MIKROE-2441
Brand: MikroElektronika
SKU: 204739



Category Motor Controller Brand MikroElektronika Condition New

Specifications

Country of Origin	India
Brand	MikroElektronika
Model	MIKROE-2441
For Use With	Small Cooling Fan in Computer, Automotive Industry, Battery Powered Systems, HVAC Systems, Computer, Small Home Appliances, medical equipment, Robotics, Toys, Drone
Kit Classification	MikroBus Click Board
Featured Device	TB6575FNG
Kit Name	Brushless Click

Key Features

Operates with external motor power supply range of 7 to 32 V DC capable of 2 A.
Uses TB6575FNG PWM sensorless controller IC for rotation speed control.
Features Pulse Width Modulation (PWM) pin for duty cycle control interface.
Includes INT pin for rotation speed sensing output and RST pin to select motor direction.
Incorporates overcurrent protection and MOSFET chips for output switching.
MCP6281 is used to prevent phase reversal during operation.
Lead angle control available at 7.5° and 15° settings.
Supports forward and reverse rotation capabilities.

Product Description

The MikroElektronika MIKROE-2441 Brushless Click Motor Controller is a mikroBUS evaluation board designed for controlling 3-phase full-wave brushless DC motors. Utilizing the Toshiba TB6575FNG PWM sensorless controller IC, it precisely regulates motor speed without requiring sensors.

This board accepts an external power supply ranging from 7 V to 32 V DC capable of delivering up to 2 A of current, making it suitable for applications in small cooling fans, automotive industry systems, battery-powered devices, HVAC systems, computers, small home appliances, medical equipment, robotics, toys, and drones.

Key control interfaces include a PWM pin for duty cycle modulation, an INT pin for sensing rotation speed output, an AN pin (VSENSE) to monitor the voltage of the DC power supply, and an RST pin to select motor rotation direction. Protection features such as overcurrent protection and MOSFET output switching ensure reliable operation without damage.

The MCP6281 operational amplifier prevents phase reversal, enhancing motor stability. Lead angle control settings of 7.5° and 15° allow performance tuning. The board supports both forward and reverse motor rotation. Its compact size of 57.15 x 25.4 mm and the 5 V power supply available via the mikroBUS socket facilitate easy integration into various development projects.

Operates with 7 to 32 V DC motor power supply capable of 2 A. TB6575FNG PWM sensorless controller IC manages motor speed. PWM pin allows duty cycle control interface. INT pin provides rotation speed sensing output. Overcurrent protection and MOSFETs control output toggling.

MCP6281 prevents phase reversal. Lead angle control selectable at 7.5° or 15°. Supports forward and reverse rotation. 5 V power supply from mikroBUS socket. Compact dimensions of 57.15 x 25.4 mm.

This evaluation board is ideal for industrial, automotive, robotics, HVAC, and electronics development applications requiring precise brushless DC motor control. MikroElektronika’s modular and compact Brushless Click Board enables rapid prototyping and integration in diverse systems.

Explore more power, motor, and robotics development tools at EnvMart to enhance your projects with advanced motor control solutions.
