HARTING 62 Way Straight 2.41 mm Pitch Through Hole D-Sub Connector with Screw Lock Male 09564617700
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 1000V |
| Brand | HARTING |
| Orientation | Straight |
| Current | 2A |
| Mount Type | Through Hole |
| Housing Material | Metal |
| Contact Material | Copper Alloy |
| Series | 956 |
| Mounting Hardware | Screw Lock |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Pitch | 2.41mm |
| Standards/Approvals | RoHS, UL 94-V0, UL Recognised |
| Contact Plating | Gold Plated |
| Number of Contacts | 62 |
| Contact Gender | Male |
| Connector Gender | Male |
| Connector Type D | D-Sub |
| D-Sub Shell Size | DS-4 |
Key Features
- Features 62 gold-plated copper alloy contacts for enhanced conductivity and reliability.
- Constructed with a durable metal housing and gold-plated stamped male pin contacts.
- Operates at a voltage rating of 1000V and current rating of 2A for industrial applications.
- Designed for through hole PCB mounting with screw lock hardware for secure installation.
- Supports operating temperature range from -40°C to 85°C for harsh environments.
- Implements a 2.41 mm pitch and DS-4 shell size for compact high-density connector solutions.
- Complies with RoHS, UL 94-V0, and UL Recognised standards for safety and quality.
- Originates from China, making it suitable for a wide range of electronic and power connector applications.
Product Description
HARTING 09564617700 is a high-density 62-way straight D-Sub connector with a 2.41 mm pitch, designed for through hole mounting on printed circuit boards (PCBs). This model features a screw lock system and male contacts, making it ideal for secure and reliable connections in electronic and power applications.
The connector incorporates gold-plated copper alloy contacts that offer excellent conductivity and resistance to corrosion, ensuring signal integrity. Its robust metal housing with dimples and stamped pins provides mechanical durability and EMI shielding.
Operating at up to 1000 V and 2 A current, this D-Sub connector supports demanding environments with an operating temperature range from -40°C to 85°C. The DS-4 shell size and 2.41 mm pitch enable compact design, maximizing contact density by approximately 70% over standard connectors.
Certified to RoHS and UL 94-V0 standards and UL Recognised, this connector meets international industrial safety and environmental compliance requirements. It is manufactured in China and is suited for use in electronic component power connections, machinery, industrial control systems, and communication equipment.
Features 62 gold-plated copper alloy contacts for excellent electrical performance. Robust metal housing with screw lock mounting for secure PCB installation. Supports high operating voltage of 1000 V and current of 2 A.
Durable design suitable for temperatures from -40°C to 85°C. Complies with RoHS and UL safety standards. Compact DS-4 shell size with 2.41 mm pitch for high-density PCB layouts. Ideal for industrial, electronic, and power connector applications requiring reliability.
The HARTING 09564617700 connector is an essential component for engineers and manufacturers needing a high-performance, compact D-Sub connector solution with secure locking and robust design characteristics. For further exploration, browse related D-Sub Connectors and HARTING brand products at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates at a voltage rating of 1000V and a current rating of 2A, making it suitable for industrial applications.
This connector supports an operating temperature range from -40°C to 85°C, allowing it to function in harsh environments.
It features 62 gold-plated copper alloy contacts, designed for enhanced conductivity and reliability.
This model is designed for through hole mounting on printed circuit boards (PCBs) and includes screw lock hardware for secure installation.
The connector implements a 2.41 mm pitch, which allows for compact high-density layouts.
It is constructed with a robust metal housing and features gold-plated stamped male pin contacts for durability and conductivity.
It complies with RoHS, UL 94-V0, and is UL Recognised, ensuring it meets international safety and environmental compliance requirements.
This model has a male connector gender, suitable for various electronic and power applications.
It uses solder termination, which is common for reliable electrical connections in PCB applications.
It features a DS-4 shell size, which is designed for high-density PCB layouts.
This connector originates from China, making it suitable for a wide range of applications in electronic and power connections.
It is suited for use in electronic component power connections, machinery, industrial control systems, and communication equipment.
