HARWIN M22 Series Right Angle Through Hole Pin Header 10 Contacts 2 mm Pitch 1 Row Unshrouded M22-2031005
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 500V |
| Brand | HARWIN |
| Orientation | Right Angle |
| Current | 1A |
| Model | M22-2031005 |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Phosphor Bronze |
| Series | M22 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 3.4mm |
| Mating Pin Length | 3.5mm |
Key Features
- Single row configuration offering 10 male contacts.
- Right angle orientation suitable for compact PCB layouts.
- Nylon housing ensures durable insulation and mechanical stability.
- Through hole mount type for robust soldered connections.
- Phosphor bronze contacts with gold plating provide excellent conductivity and corrosion resistance.
- Designed to operate between -40°C and 105°C for varied environmental conditions.
- Supports electrical rating up to 500V and 1A current.
- Tail pin length is 3.4mm and mating pin length is 3.5mm for precise fitment.
Product Description
HARWIN M22-2031005 is a high-quality right angle through hole pin header designed for electronic PCB board-to-board connector systems. It features a single row of 10 male contacts spaced with a 2 mm pitch, housed in durable nylon for insulation and mechanical integrity. The unshrouded style offers straightforward soldering and assembly.
This pin header supports operating temperatures ranging from -40°C up to 105°C, ensuring reliability in industrial, manufacturing, and electronic assembly environments. The contacts are made of phosphor bronze and plated with gold for superior electrical conductivity and corrosion resistance, suitable for currents up to 1 ampere and voltages up to 500 volts.
The right angle orientation enables effective space-saving layouts on printed circuit boards. Tail pin length of 3.4 mm and mating pin length of 3.5 mm guarantee precise mechanical and electrical connection. It is designed to be mounted through hole style, providing robust soldered joint strength for reliable long-term performance.
This pin header series is commonly used in electronics manufacturing, embedded systems, industrial control equipment, and prototype development applications. Its durability and electrical specifications make it suitable for demanding conditions requiring stable connector performance.
Single row angled pin header with 10 male contacts. 2 mm pitch spacing ensures elegant PCB connectivity. Nylon housing delivers insulation and mechanical protection. Gold-plated phosphor bronze contacts increase conductivity.
Operating temperature range from -40°C to 105°C. Right angle design saves space on circuit boards. Through hole mounting method for strong solder joints. Voltage rating up to 500V and current rating of 1A. Unshrouded connector for easy solder access.
Applications include industrial electronics and manufacturing. Explore more electronics connectors and components with EnvMart's extensive collection for demanding industrial and commercial projects.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The HARWIN M22-2031005 pin header supports a voltage rating of up to 500V.
This model is rated for a maximum current of 1A.
The contacts of this pin header are spaced at a 2 mm pitch.
The housing is made of nylon, while the contacts are made of phosphor bronze with gold plating for enhanced conductivity.
It operates within a temperature range of -40°C to 105°C.
The HARWIN M22-2031005 features a total of 10 male contacts.
This model utilizes a through hole mounting type for robust soldered connections.
The tail pin length is 3.4 mm, while the mating pin length is 3.5 mm.
The HARWIN M22-2031005 is an unshrouded connector, allowing for easy solder access.
It is commonly used in electronics manufacturing, embedded systems, and industrial control equipment.
This model has a right angle orientation, which is suitable for compact PCB layouts.
It is designed for board-to-board connector systems.
