Vishay Single Layer Ceramic Capacitor 2.5 nF 15kV DC Through Hole Z5U Dielectric 615R Series 105°C 615R150GAD25
Specifications
| Country of Origin | Czech Republic |
|---|---|
| Voltage | 15kV dc |
| Diameter | 24.9mm |
| Brand | Vishay |
| Model | 615R150GAD25 |
| Width | 11.4mm |
| Mount Type | Through Hole |
| Series | 615R |
| Maximum Operating Temperature | 105°C |
| Tolerance | -20 to 80 % |
| Capacitance | 2.5nF |
| Minimum Operating Temperature | -25°C |
| Terminal type | Radial |
| Dissipation Factor | 2% |
| Standards/Approvals | RoHS, EC |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 131-1211PBrand: VishayManufacturers Part No.: 615R150GAD25 |
| Pin Count | 2 |
| Dielectric | Z5U |
| Suppression Class | Class II |
Key Features
- High capacitance in a compact ceramic disc design.
- Operating temperature range from -25°C to 105°C for versatile use.
- Dielectric of Z5U type with -20 to 80 % tolerance.
- Radial terminal type with two pins and Class II suppression class.
- Low dissipation factor of 2% ensures energy efficiency.
- Silver-plated ceramic disc coated with flame retardant epoxy resin.
- Designed for applications including TV, monitors, X-ray equipment, and switched mode power supplies.
- Manufactured in the Czech Republic following RoHS and EC standards.
Product Description
Vishay 615R150GAD25 Single Layer Ceramic Capacitor is engineered for high voltage and power stability applications, rated at 2.5 nF capacitance and 15kV DC voltage, designed with a through hole mounting style and Z5U dielectric. It operates reliably within temperatures from -25°C to 105°C.
This 615R series capacitor features a ceramic disc construction with silver plating on both sides and a flame retardant epoxy coating, ensuring durability and safety in demanding environments. The radial terminal type enables secure installation with two pins for effective circuit connection.
The capacitor exhibits a tolerance range of -20 to 80 %, a dissipation factor of 2%, and a Class II suppression classification, which together optimize stability and suppress unwanted electrical noise. These characteristics make it ideal for use in TVs, monitors, DC and pulse high voltage systems, X-ray equipment, and switched mode power supplies (SMPS).
Manufactured under RoHS and EC compliance standards in the Czech Republic, this capacitor balances performance and environmental considerations. The compact form factor with a diameter of 24.9 mm and width of 11.4 mm fits well into densely packed circuit boards, supporting efficient design.
High capacitance with small size for compact circuits. Low losses for enhanced reliability and energy efficiency. Radial tinned copper leads for robust electrical connections. Flame retardant epoxy coating for safety in power applications.
Application versatility including electronics and medical imaging devices. Explore more high-quality electronic components and capacitors in the Vishay range on EnvMart, your source for industrial-grade electronics and electrical parts.
Explore more products in our Single Layer Ceramic Capacitors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Vishay 615R150GAD25 capacitor has a capacitance rating of 2.5 nF.
This model is rated for a maximum voltage of 15kV DC.
It operates reliably within a temperature range of -25°C to 105°C.
The capacitor features a Z5U type dielectric.
The Vishay 615R150GAD25 is designed for through hole mounting with a radial terminal type.
The capacitor has a diameter of 24.9 mm and a width of 11.4 mm.
It has a tolerance range of -20 to 80%.
The dissipation factor is 2%.
This capacitor is suitable for applications including TVs, monitors, X-ray equipment, and switched mode power supplies.
It is manufactured in compliance with RoHS and EC standards.
This model features two pins for connection.
The Vishay 615R150GAD25 is manufactured in the Czech Republic.
