Vishay Single Layer Ceramic Capacitor 2.5 nF 15 kV DC Z5U Dielectric Through Hole 105 °C Max Op. Temp 615R150GAD25

Vishay 615R150GAD25 Single Layer Ceramic Capacitor is designed for high voltage and stability demanding applications, featuring a capacitance of 2.5 nF and voltage rating of 15 kV DC. It uses the Z5U dielectric, offering a tolerance range of -20 to +80 percent and supports through-hole mounting with radial leads for ease of circuit board integration.

This capacitor has a diameter of 24.9 mm and width of 11.4 mm, making it compact for high power circuits. Operating temperature ranges from -25°C to a maximum of 105°C, suitable for industrial and commercial environments.

The 615R series capacitors are silver plated on both ceramic disc sides and coated with flame retardant epoxy, enhancing durability and fire resistance. Radial tinned copper leads ensure reliable soldering and mechanical connection.

Applications include TVs, monitors, DC and pulse high voltage circuits, X-ray equipment, and switched mode power supplies (SMPS), underlining its versatility in electronic assemblies.

This component complies with RoHS and EC environmental standards, affirming its safety and regulatory conformity for use in global markets. It is manufactured in the Czech Republic and is known for low losses and high reliability.

Capacitance of 2.5 nanofarads suitable for high power circuits. Rated voltage of 15 kV DC for high voltage stability. Uses Z5U dielectric material providing reliable performance. Through Hole mounting with radial terminal type.

Maximum operating temperature of 105 degrees Celsius ensuring thermal durability. Class II suppression class for noise filtering applications. Silver-plated ceramic disc coated with flame retardant epoxy resin. Tinned copper radial leads for strong solder connections.

Typical applications include TV, monitors, X-ray equipment, and switched mode power supplies. Compliance with RoHS and EC standards for environmental safety.

For business, industrial, and laboratory use cases requiring precision high voltage capacitors, the Vishay 615R150GAD25 offers a trusted solution. Explore additional Vishay electronics components and capacitors on EnvMart for a complete electronic components sourcing experience.
