Vishay 100 V 1 A Diode General Purpose 2-Pin DO-214AC To ES1B-E3/5AT

Vishay To ES1B-E3/5AT is a general purpose Schottky diode featuring a 2-pin DO-214AC (SMA) low profile surface mount package designed for reliable performance in semiconductor applications requiring a 100V voltage capacity and 1A current rating. It is suited for high frequency rectification and freewheeling use in switching mode converters and inverters across consumer electronics, computer, automotive, and telecommunication applications.

The diode incorporates a glass passivated pellet chip junction that provides high efficiency and low power loss during operation. Its ultrafast recovery time of 25 nanoseconds allows for effective switching, minimizing energy dissipation while the low forward voltage drop of 920 millivolts enhances energy efficiency.

This device supports a maximum continuous forward current of 1 ampere and a peak non-repetitive forward surge current of 30 amperes, making it capable of handling transient surge conditions in industrial and automotive environments. The matte tin plated leads are designed for standard solderability, compliant with J-STD-002 and JESD 22-B102 standards.

Operating temperature range spans from -55°C to a maximum of 150°C, ensuring dependable performance under extreme conditions. The diode meets the automotive industry standard AEC-Q101, with specific ordering codes available for automotive grade variants. Polarity is easily identified via a color band marking on the cathode end for correct orientation during PCB assembly.

Its compact dimensions (4.5mm length, 2.79mm width, and 2.09mm height) and surface mount form factor support automated placement for efficient manufacturing processes. The rugged SMA case offers UL 94 V-0 flammability rating for safety compliance.

Equipped with a low profile DO-214AC SMA package for efficient mounting. Supports maximum continuous forward current of 1 ampere. Features peak reverse repetitive voltage of 100 volts, suitable for high frequency rectification.

Operates reliably between -55°C and 150°C ambient temperatures. Offers ultrafast recovery times of 25 nanoseconds, enhancing performance in switching applications. Contains matte tin plated leads compatible with standard soldering processes.

Glass passivated pellet chip junction ensures high durability and efficiency. High forward surge capability up to 30 amperes peak non-repetitive current. Adheres to automotive standard AEC-Q101 for quality assurance. Indicated polarity by color band denoting the cathode end.

This Vishay diode is ideal for industrial, automotive, telecommunications, computer, and consumer electronics uses requiring high efficiency and reliability in rectifier and switching circuits. Its broad temperature range and high surge tolerance make it well suited for demanding environmental conditions.
