TDK-Lambda DC/DC Converter Through Hole 3.3V DC Output 4A 18V-76V DC Input 13.2W 85°C Max Temp CCG15

TDK-Lambda CCG15 DC/DC Converter is a high-performance power supply component designed for industrial and commercial applications. This through hole mounted device delivers a stable 3.3V DC output voltage at 4A current with a maximum output power of 13.2W. It supports a wide input voltage range from 18V to 76V DC, making it adaptable for various DC power sources.

The converter boasts an efficiency of 85%, reducing power loss and heat generation during operation. It is packaged in a compact DIP form factor measuring 25.4mm in length, and 9.9mm in both width and depth, suitable for space-constrained PCB layouts. Its metal casing with six-sided shielding minimizes electromagnetic interference and provides excellent resistance against shock and vibration, enhancing system reliability.

Rated for a broad operating temperature range from -40°C to +85°C, the CCG15 is suitable for harsh environmental conditions commonly found in industrial, laboratory, and factory automation settings. The device features an isolation voltage of 500V DC and low output noise with 95mV peak-to-peak ripple and noise specifications.

This DC/DC converter complies with CE, EN 60950-1, and UL/CSA 60950-1 safety standards, ensuring robust and safe operation. Typical applications include test and measurement instruments, broadcast equipment, communication devices, general industrial machinery, and process control systems.

Provides stable 3.3V DC output at 4A current capacity. Supports wide input voltage range from 18V to 76V DC for versatile usage. Compact through hole DIP package measuring 25.4mm x 9.9mm x 9.9mm. High efficiency of 85% reduces power loss and heat generation.

Operates reliably within -40°C to +85°C ambient temperatures. Six-sided metal shielding reduces electromagnetic noise and enhances durability. Isolation voltage rated at 500V DC for safe operation. Low output ripple and noise of 95mV Pk-Pk enhances signal quality.

Compliant with CE, EN 60950-1, and UL/CSA 60950-1 standards. Suitable for test equipment, communication, factory automation, and industrial applications. Explore our extensive range of DC/DC Converters at EnvMart for reliable power management solutions in your electronics and industrial projects.
