Schneider Electric LC1K Contactor, 230V AC Coil, 4-Pole, 20A, 1.3W Power Rating, 4 NO, 690V AC Contact Voltage LC1K09004P7
Specifications
| Country of Origin | France |
|---|---|
| Brand | Schneider Electric |
| Function | Motor Control |
| Length | 58mm |
| Model | LC1K09004P7 |
| Depth | 57mm |
| Width | 45mm |
| Mount Type | DIN Rail |
| Series | LC1K |
| Power Rating | 1.3W |
| Maximum Operating Temperature | 50°C |
| Minimum Operating Temperature | -25°C |
| Terminal type | Screw |
| Number of Poles | 4 |
| Standards/Approvals | CCC, CSA, EAC, IEC, RoHS, UL |
| Contact Voltage | 690V ac |
| Coil Voltage | 230V ac |
| Normal State Configuration | 4 NO |
| Better World Claim | Designed for Disassembly |
| Contact Current | 20A |
| Operational Current Ie | 20A |
| Control Circuit Voltage Uc | 230V ac |
| Contactor Application | Motor Control |
| Pole and Throw Configuration | 4 |
| Screw connections | IP20 finger-safe terminals with both North American and International terminal markings |
| AC-1 | This applies to all AC devices with a power factor of at least 0.95. Example of use: resistive load, heating, distribution |
| AC-3 | This applies to squirrel cage motors where breaking occurs while the motor is running |
| Example of use | all squirrel cage motors, lifts, escalators, conveyors, bucket elevators, compressors, pumps, mixers, air conditioning units |
Key Features
- Compact size with dimensions of 58mm length, 57mm depth, and 45mm width for space-constrained installations.
- Operates reliably within a temperature range of -25°C to 50°C, suitable for harsh environments.
- Features 4 Normally Open (NO) contacts rated for 690V AC contact voltage and 20A current capacity.
- IP20 finger-safe rating offers protection against dust and accidental finger contact.
- Mounts easily on DIN rails or panels using screws, providing flexible installation options.
- Lightweight at merely 180 grams, minimizing added mechanical load.
- Complies with international standards including CCC, CSA, EAC, IEC, RoHS, and UL for assured quality and safety.
- Offers a mechanical lifespan of up to 10 million cycles, ensuring durability in continuous industrial use.
Product Description
Schneider Electric LC1K09004P7 Contactor is a reliable 4-pole device designed for motor control applications with a coil voltage of 230V AC and power rating of 1.3 Watts. It is part of the TeSys K series renowned for long mechanical and electrical life, making it ideal for industrial automation and heavy-duty environments.
Designed for compactness, its dimensions (58mm L x 57mm D x 45mm W) allow installation in space-tight panels while maintaining user safety with IP20 finger-safe terminals. The contactor features four Normally Open contacts rated at 20A and 690V AC contact voltage, suitable for controlling inductive loads in motor-driven equipment.
With an operating temperature range from -25°C up to 50°C, it suits harsh industrial conditions. Its lightweight design (180 grams) reduces mechanical stress on mounting structures. Installation versatility is enhanced through both DIN rail mounting and screw panel fixing options.
Compliance to CCC, CSA, EAC, IEC standards, RoHS, and UL assures stringent quality and safety norms. It is free from mercury and other toxic heavy metals, supporting environmentally responsible usage.
The mechanical lifespan extends up to 10 million cycles, reinforcing its suitability for continuous heavy industrial workloads such as workshops, agricultural machinery, and manufacturing plants.
Compact size with dimensions of 58mm length, 57mm depth, and 45mm width for space-constrained installations. Operates reliably within a temperature range of -25°C to 50°C, suitable for harsh environments. Features 4 Normally Open (NO) contacts rated for 690V AC contact voltage and 20A current capacity.
IP20 finger-safe rating offers protection against dust and accidental finger contact. Mounts easily on DIN rails or panels using screws, providing flexible installation options. Lightweight at merely 180 grams, minimizing added mechanical load.
Complies with international standards including CCC, CSA, EAC, IEC, RoHS, and UL for assured quality and safety. Offers a mechanical lifespan of up to 10 million cycles, ensuring durability in continuous industrial use. Eco-friendly design free from mercury and heavy toxic metals, aligning with sustainability goals.
This contactor is ideal for electrical automation tasks in heavy industries, workshops, agricultural equipment, and motor control systems. Schneider Electric offers this product as part of its Better World range, emphasizing sustainability and design for disassembly.
Explore more Contactors and automation solutions in the Electronics & Electricals Automation & Control Gear category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The power rating of this model is 1.3 Watts.
It has a maximum contact voltage rating of 690V AC.
This contactor can handle a current capacity of 20A.
The dimensions are 58mm in length, 57mm in depth, and 45mm in width.
It operates reliably within a temperature range of -25°C to 50°C.
This model features 4 poles.
It has IP20 finger-safe terminals with screw connections.
It can be mounted on DIN rails or panels using screws.
It complies with international standards including CCC, CSA, EAC, IEC, RoHS, and UL.
The mechanical lifespan extends up to 10 million cycles.
It is suitable for motor control applications, including use with squirrel cage motors, lifts, escalators, and pumps.
The coil voltage for this contactor is 230V AC.
