RS PRO Industrial Circular Connector, 3 Contacts, Flange Mount, Socket Female, 10A, 500V, IP68, Polyamide 66 Shell 124-6678
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 500V |
| Brand | RS PRO |
| Orientation | Straight |
| Current | 10A |
| Model | 124-6678 |
| IP Rating | IP68 |
| Mount Type | Flange |
| Housing Material | Polyamide 66, Polycarbonate |
| Contact Material | Brass |
| Series | RS PRO |
| Termination Type | Screw |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Pole Format | 3 |
| Contact Plating | Gold |
| Number of Contacts | 3 |
| Contact Gender | Female |
| Shell Size | 21 mm |
| Mating Type | Threaded |
| Connector Size | Standard |
| Plug/Socket | Socket |
| Cable outer diameter acceptance | 4.5 mm - 7 mm |
| Panel hole cutout diameter | 21 mm |
Key Features
- This circular connector features a durable polyamide 66 and polycarbonate shell that provides robust protection in demanding conditions.
- The connector has a 3-contact female socket design with screw termination for secure electrical connections.
- It is flange mounted with a 2-hole design for stable and reliable attachment to panels or equipment.
- Rated for a current of 10A and voltage of 500V, making it suitable for a wide range of industrial applications.
- The connector is built to operate within a temperature range of -40°C to 85°C ensuring versatility in varying climates.
- Gold-plated brass contacts ensure excellent electrical conductivity and resistance to corrosion.
- Threaded mating type and straight orientation enhance connection stability and ease of use.
- Cable outer diameter acceptance ranges from 4.5 mm to 7 mm for flexible wiring options.
Product Description
RS PRO 124-6678 is a high-quality industrial circular connector designed to provide reliable connections in demanding applications. Featuring a robust polyamide 66 and polycarbonate housing, this flange-mounted socket connector is designed for durability and protected against environmental challenges with an IP68 rating, making it suitable for use in industrial, manufacturing, and automation environments.
The connector contains 3 gold-plated brass contacts for optimal electrical performance and corrosion resistance. It is rated for 10A current and 500V voltage, allowing it to handle moderate power levels safely. The termination is via screws, providing secure and stable wiring connections.
This connector is designed with a 2-hole flange mount to ensure firm attachment to panels or equipment. The shell size measures 21 mm with a cable diameter acceptance of 4.5 mm to 7 mm, accommodating a range of cable sizes. The threaded mating type and straight orientation ensure a solid and reliable connection.
Rated for operation from -40°C to 85°C, the connector can operate reliably in varying temperature environments, making it highly versatile for industrial applications that require rugged and weather-proof connectivity.
The connector is ideal for industrial automation, machinery, control systems, power distribution, and any application needing a secure, IP68 rated circular connector. This circular connector features a durable polyamide 66 and polycarbonate shell that provides robust protection in demanding conditions.
The connector has a 3-contact female socket design with screw termination for secure electrical connections. It is flange mounted with a 2-hole design for stable and reliable attachment to panels or equipment. Rated for a current of 10A and voltage of 500V, making it suitable for a wide range of industrial applications.
The connector is built to operate within a temperature range of -40°C to 85°C ensuring versatility in varying climates. Gold-plated brass contacts ensure excellent electrical conductivity and resistance to corrosion. Threaded mating type and straight orientation enhance connection stability and ease of use.
Cable outer diameter acceptance ranges from 4.5 mm to 7 mm for flexible wiring options. Panel hole cutout diameter is 21 mm, matching standard industrial panel sizes. Provides IP68 ingress protection rating to prevent dust and water ingress in harsh environments.
Explore the RS PRO brand and wide range of Industrial Circular Connectors on EnvMart for reliable and high-performance connectivity solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a current of 10A and a voltage of 500V, making it suitable for various industrial applications.
It has an IP68 rating, which provides protection against dust and water ingress, suitable for harsh environments.
The housing is made from polyamide 66 and polycarbonate, while the contacts are gold-plated brass for optimal conductivity and corrosion resistance.
It operates within a temperature range of -40°C to 85°C, ensuring versatility in various climates.
This connector features a flange mount design with a 2-hole configuration for stable attachment to panels or equipment.
It accepts cable outer diameters ranging from 4.5 mm to 7 mm, providing flexibility for wiring options.
This model has 3 contacts and features a female socket design.
The connector utilizes screw termination, ensuring secure and stable electrical connections.
The panel hole cutout diameter is 21 mm, which matches standard industrial panel sizes.
The connector has a straight orientation, which enhances connection stability and ease of use.
It is suitable for industrial automation, machinery, control systems, and power distribution, among other applications requiring secure connectivity.
