SMC Pneumatic Guided Cylinder 20mm Bore Double Acting MGQ Series EMGQM20-20

Free Delivery in India | Lowest Global Shipping Charges

SMC Pneumatic Guided Cylinder 20mm Bore Double Acting MGQ Series EMGQM20-20



Category Pneumatic Guided Cylinder Brand SMC Condition New

Specifications

Country of Origin	France
Brand	SMC
Maximum Operating Pressure	1 Mpa
Height	74mm
Length	67mm
Model	EMGQM20-20
Gross Weight	540g
Width	36mm
Mount Type	Direct
Series	MGQ
Maximum Operating Temperature	60°C
Minimum Operating Temperature	-10°C
Stroke Length	20mm
Bore Diameter	20mm
Rod Type	Single
Action Type	Double Acting
Cushioning Type	Rubber
Guide Type	Slide Bearing, Ball Bearing

Key Features

The cylinder features a 20mm bore diameter suitable for precise linear actuation.
Double acting mechanism provides controlled motion both directions for versatile applications.
Compact MGQ Series includes a slide bearing and ball bearing for enhanced guide functionality.
Direct mounting type with pre-tapped holes ensures easy and secure fixture attachment.
Rubber cushioning improves operational smoothness and reduces impact noise.
Operates reliably within temperatures from -10°C to 60°C, fitting diverse environments.
Maximum operating pressure is rated at 1 Mpa for robust pneumatic performance.
Stroke length is 20mm, enabling precise, short travel movements in automation systems.

Product Description

SMC EMGQM20-20 Pneumatic Guided Cylinder 20mm Bore Double Acting MGQ Series is designed to provide high-performance linear actuation in industrial pneumatic applications. This compact guide cylinder excels in handling high loads while maintaining exceptional non-rotational accuracy, making it ideal for material handling and automation tasks.

It features a 20mm bore diameter and a 20mm stroke length, allowing precise controlled movement. The double acting design ensures force in both directions, enhancing operational flexibility. The cylinder employs slide and ball bearings to support smooth guidance and withstand side loads effectively.

With a maximum operating pressure of 1 Mpa and operating temperature range from -10°C to 60°C, the EMGQM20-20 is suitable for diverse manufacturing, laboratory, and industrial environments. Its rubber cushioning improves cycle smoothness, reducing noise and wear during operation.

The direct mount type with pre-tapped holes simplifies fixture installation on side or bottom surfaces, facilitating quick integration into pneumatic systems. Weighing only 540 grams, this French-manufactured guided cylinder combines durability with lightweight design, reinforcing its suitability for complex pneumatic automation setups.

The cylinder features a 20mm bore diameter suitable for precise linear actuation. Double acting mechanism provides controlled motion in both directions. Compact MGQ Series includes slide and ball bearings for superior guidance.

Direct mounting with pre-tapped holes ensures easy attachment of fixtures. Rubber cushioning reduces impact noise and smooths operation. Operating temperature range from -10°C to 60°C supports various environments. Maximum pressure rating of 1 Mpa for robust pneumatic power.

Stroke length of 20mm enables precise short travel motion. Lightweight design at 540 grams for simple system integration. Manufactured in France under strict quality standards.

This guided pneumatic cylinder is well-suited for use in industrial automation, manufacturing processes, and material handling applications where precision and durability are critical. It adds reliable linear actuation capability to pneumatic systems in commercial and industrial plants.
