Eaton Cartridge Fuse 2A Current Rating, 5 x 20 mm Glass Body, Time Delay, 250V AC S506-2-R
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 250V ac |
| Diameter | 5mm |
| Brand | Eaton |
| Body Material | Glass |
| Model | S506-2-R |
| Overall Length | 20mm |
| Current Rating | 2A |
| Series | S506 |
| Standards/Approvals | VDE, UL, SEMKO, IMQ, CSA, CCC, BSI |
| Fuse Characteristics | Time Delay |
| Fuse Size | 5 x 20 mm |
| Cooper Bussmann Cartridge FuseBrand | Cooper Bussmann |
| Littelfuse 2A T Glass Cartridge Fuse, 5 x 20 mmBrand | Littelfuse |
| Anti surge T LBC min fuse,2A 5x20mmBrand | Cooper Bussmann |
Key Features
- This cartridge fuse provides reliable circuit protection in electrical, automation, and electronic systems.
- The glass body allows easy visual inspection of the fuse element.
- Time delay fuse characteristic prevents nuisance blowing during inrush current surges.
- Approved by multiple standards including VDE, UL, SEMKO, IMQ, CSA, CCC, and BSI.
- Compact size with 20 mm overall length and 5 mm diameter fits standard fuse holders.
- Operates reliably within a temperature range of -40°C to +125°C.
- Suitable for low-voltage electrical installations and sensitive electronic applications.
Product Description
Eaton S506-2-R Cartridge Fuse is a high-quality electrical protection component with a 2 amp current rating and 250 volts AC voltage capacity. This fuse features a 5 x 20 mm glass body construction which offers clear visibility for monitoring the fuse status without removal.
Designed with a time delay fuse characteristic, the Eaton S506-2-R effectively prevents nuisance blowing caused by temporary surges or inrush currents, making it ideal for sensitive automation and electronic control circuits.
The fuse complies with IEC 60127-2 standards and carries approvals from VDE, UL, SEMKO, IMQ, CSA, CCC, and BSI, ensuring robust safety and operational compliance across industrial and commercial applications.
With a compact form factor measuring 20 mm in length and 5 mm in diameter, installation is straightforward in standard fuse holders. The glass construction not only facilitates quick inspection but also contributes to the fuse’s reliable operation over a broad temperature range from -40°C to +125°C.
This Eaton cartridge fuse is widely used in automation systems, mechanical industries, and low-voltage electrical setups requiring precise overload protection. Its time delay functionality allows it to withstand temporary overloads typical in motor and transformer start-ups without blowing prematurely.
Reliable circuit protection in automation and electronic systems. Glass body facilitates easy visual inspection of the fuse element. Time delay characteristic resists nuisance blowing from surges. Certified to meet multiple international standards ensuring quality and safety.
Compact 5 x 20 mm size enables use in standard fuse holders. Durable performance across a wide operating temperature range. Ideal for sensitive low-voltage electrical and mechanical applications. Set includes 1 Pc Eaton 2A T Glass Cartridge Fuse, model S506-2-R. Eaton formerly known as Bussmann.
Explore more high-quality electrical protection components in EnvMart’s curated catalog for industrial and commercial uses.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Eaton S506-2-R cartridge fuse has a current rating of 2A.
This model operates at a voltage capacity of 250V AC.
The fuse has a diameter of 5 mm and an overall length of 20 mm.
The Eaton S506-2-R features a glass body construction, allowing for easy visual inspection of the fuse element.
This cartridge fuse has a time delay characteristic, which helps prevent nuisance blowing during inrush current surges.
The Eaton S506-2-R is approved by multiple standards including VDE, UL, SEMKO, IMQ, CSA, CCC, and BSI.
This model operates reliably within a temperature range of -40°C to +125°C.
It is suitable for low-voltage electrical installations and sensitive electronic applications, particularly in automation systems.
The time delay feature allows it to withstand temporary overloads typical in motor and transformer start-ups without blowing prematurely.
The fuse size is 5 x 20 mm, which fits standard fuse holders.
Yes, this fuse is designed to provide reliable circuit protection in automation and electronic control circuits.
The country of origin for the Eaton S506-2-R is China.
