ITW Switches Short Roller Lever Micro Switch, Solder Terminal, 8A, 250 V AC, 28 V DC, DPDT-DB, IP67 26-804

Free Delivery in India | Lowest Global Shipping Charges

ITW Switches Short Roller Lever Micro Switch, Solder Terminal, 8A, 250 V AC, 28 V DC, DPDT-DB, IP67 26-804

Name: ITW Switches Short Roller Lever Micro Switch, Solder Terminal, 8A, 250 V AC, 28 V DC, DPDT-DB, IP67 26-804
Brand: ITW Switches
SKU: 195426
Price: 62.6 USD
Availability: InStock



Category Micro Switches Brand ITW Switches Condition New

Specifications

Country of Origin	India
Brand	ITW Switches
Model	26-804
IP Rating	IP67
Series	26
Maximum Operating Temperature	275°F
Contact Configuration	DPDT-DB
Actuator Type	Short Roller Lever
Terminal type	Solder
Standards/Approvals	CSA, RoHS, UL
Contact DC Voltage	28V dc
Switch Contact Current	8A
Operating Force	12oz
Contact AC Voltage	250V ac
Microswitch Type	Snap-In Latch

Key Features

Features a short roller lever actuator for precise control.
Solder terminal type ensures secure electrical connections.
DPDT-DB (Double Pole Double Throw - Double Break) contact configuration controlling two independent circuits.
Rated for 250 V AC and 28 V DC operation.
IP67 rated for dust tight and water immersion protection.
Operating force is approximately 12 oz for reliable actuation.
Maximum operating temperature up to 275°F (135°C).
Snap-In Latch microswitch type offering easy installation and removal.

Product Description

ITW Switches 26-804 Short Roller Lever Micro Switch offers robust electrical switching capability with a maximum contact current of 8A. It features a short roller lever actuator combined with a solder terminal design, enabling dependable connections in demanding industrial and automation environments.

This microswitch is designed with a DPDT-DB contact configuration, allowing it to control up to four isolated circuits by wiring two commons externally, making it adaptable for complex switching tasks. It operates efficiently at both 250 V AC and 28 V DC, ensuring versatility for AC and DC electrical systems.

The switch is rated IP67, guaranteeing protection against dust ingress and temporary immersion in water, making it suitable for harsh industrial applications. With an operating force of 12 ounces (approximately 3.36 Newtons) and a maximum operating temperature of 275°F, this switch withstands demanding mechanical and thermal conditions.

Its snap-in latch microswitch type provides ease of installation, while certifications including CSA, RoHS, and UL attest to its compliance with international standards for safety and environmental responsibility.

Applications include use in aircraft rotary actuators, aircraft valve actuators, circuit breakers, aircraft contractors, and various industrial machinery, where reliability and precision are critical.

Features a short roller lever actuator for precise control. Solder terminal type ensures secure electrical connections. DPDT-DB (Double Pole Double Throw - Double Break) contact configuration controlling two independent circuits.

Rated for 250 V AC and 28 V DC operation. IP67 rated for dust tight and water immersion protection. Operating force is approximately 12 oz for reliable actuation. Maximum operating temperature up to 275°F (135°C). Snap-In Latch microswitch type offering easy installation and removal.

Certified under CSA, RoHS, and UL standards for quality assurance.

This product is ideal for industrial automation, electrical control systems, aerospace applications, and manufacturing equipment requiring dependable micro switch performance. Browse more Micro Switches and automation components at EnvMart for comprehensive industrial solutions.
