TE Connectivity MTA-156 Series Straight Through Hole Pin Header 12 Contacts 3.96 mm Pitch 1 Row Unshrouded 1-640383-2
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 600V |
| Brand | TE Connectivity |
| Orientation | Straight |
| Current | 7A |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Copper Alloy |
| Series | MTA-156 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -65°C |
| Number of Rows | 1 |
| Pitch | 3.96mm |
| Contact Plating | Tin |
| Number of Contacts | 12 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.56mm |
Key Features
- This pin header features a single row of 12 male contacts designed for through hole mounting.
- The housing is made of glass filled polyester providing durability and meets UL94V-0 standards.
- It is unshrouded with tin-plated copper alloy contacts for reliable solder termination.
- Rated for 600 V voltage and 7 A current with operating temperatures from -65°C to 105°C.
- The tail pin length is 3.56 mm with a pitch and row spacing of 3.96 mm, ideal for wire-to-board applications.
- This MTA-156 connector series uses IDC technology enabling one-step wire assembly and supporting 26 to 18 AWG wires.
Product Description
TE Connectivity 1-640383-2 MTA-156 Series straight through hole pin header is a high-performance PCB connector designed for reliable wire-to-board connections in industrial and electronic applications.
This connector has 12 male contacts arranged in a single row with a 3.96 mm pitch, facilitating precise and consistent mating with corresponding sockets. The housing is constructed from UL94V-0 rated white glass filled polyester to ensure robust insulation and flame resistance under demanding conditions.
The contacts are made from copper alloy with tin plating to provide excellent electrical conductivity and corrosion resistance, terminated via soldering with a 3.56 mm tail pin length.
Operating voltage is rated up to 600 V, and current handling up to 7 A with a wide temperature range from -65°C to 105°C allowing use in harsh environments.
This connector system supports insulation displacement contact (IDC) technology for rapid assembly with discrete wires or ribbon cables, suitable for 26 AWG to 18 AWG wire sizes, aiding in labor and cost-saving mass termination processes.
Features single row, 12 contacts for compact PCB layout flexibility. Unshrouded design allows easy inspections and solder checks. Glass filled polyester housing ensures durability and flame retardancy. Compatibility with MTA-156 series IDC connectors enhances system integration.
Suitable for applications in industrial electronics, automotive, and communication equipment. Facilitates wire-to-board connections requiring robust, reliable electrical performance. This pin header is an essential component for manufacturers needing dependable and efficient PCB interconnection solutions.
Explore more TE Connectivity PCB Headers and compatible accessories on EnvMart for your industrial electronics needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this pin header is 600 V.
This model is rated for a maximum current of 7 A.
The pitch of the contacts is 3.96 mm.
The housing is made of glass filled polyester, and the contacts are made from copper alloy with tin plating.
The tail pin length is 3.56 mm.
It can operate within a temperature range of -65°C to 105°C.
This pin header features 12 male contacts arranged in a single row.
The termination type for this model is solder.
This model is unshrouded, allowing for easy inspections and solder checks.
It is suitable for wire-to-board connections in industrial electronics, automotive, and communication equipment.
The orientation of this connector is straight.
The country of origin for this pin header is India.
