Cynergy3 RSF80 Series Horizontal Float Switch, NO/NC, 300V AC Max, 300V DC Max RSF87HP/RS

Name: Cynergy3 RSF80 Series Horizontal Float Switch, NO/NC, 300V AC Max, 300V DC Max RSF87HP/RS
Brand: Cynergy3
SKU: 194744
Price: 44.17 USD
Availability: InStock



Category Float Switches Brand Cynergy3 Condition New

Specifications

Country of Origin	China
Brand	Cynergy3
Model	RSF87HP/RS
Mount Type	Horizontal
Housing Material	Polyvinyl Fluoride
Series	RSF80
Maximum Operating Temperature	105°C
Switch output	NO/NC
Minimum Operating Temperature	-10°C
Maximum Current	1A
Maximum dc Voltage	300V dc
Standards/Approvals	UL
Maximum AC Voltage	300V ac

Key Features

Constructed with PVDF housing resistant to diesel and hydraulic oils.
Operating temperature range from -10°C to 105°C for versatile applications.
Maximum switching current of 1A ensures efficient operation.
M12 circular connector socket allows for easy installation and connection.
180° rotatable switch action for sensing rising or falling liquid levels.
Designed for external tank wall mounting, avoiding tank interior access.
Overall length 90mm with 18mm threaded section for accurate liquid level detection.

Product Description

Cynergy3 RSF87HP/RS horizontal float switch from the RSF80 series is engineered for precise liquid level monitoring in industrial and commercial tanks. This switch supports NO/NC switching output and operates up to 300V AC and 300V DC, covering a wide range of voltage applications.

The housing material is polyvinylidene fluoride (PVDF), a chemically resistant and abrasion-proof plastic compatible with fluids such as diesel fuel and hydraulic oil, ensuring durability in harsh environments. The device functions efficiently in temperatures ranging from -10°C to 105°C, making it suitable for demanding industrial environments.

This float switch features a maximum current rating of 1A for switching, balancing power and energy efficiency. Its M12 circular connector socket design facilitates straightforward installation. The float switch can be rotated 180 degrees to change the switching action and is suitable for monitoring both rising and falling liquid levels.

Because it mounts externally through the tank wall, the switch does not require internal tank access, which simplifies maintenance and installation. The device measures 90mm in length including the 18mm threaded portion, providing sufficient reach for exact liquid level detection.

Chemical-resistant PVDF housing ensures longevity in various fluid environments. Robust switching capabilities with 1A maximum current rating. Wide temperature tolerance supports operation in challenging conditions. External mounting eliminates the need for tank interior installation access.

180° adjustable switching for flexible sensing applications. Compact 90mm length accommodates installation in diverse tank sizes.

This float switch is ideal for industrial, manufacturing, water treatment, and agricultural uses where precise liquid level monitoring is critical. It is often applied in diesel generators, gearbox oil tanks, and other fluid storage tanks requiring reliable and maintenance-friendly level sensing.

Explore full Cynergy3 offerings and other sensor solutions available at EnvMart for enhanced automation and fluid management.
