ATC 0805 Unshielded Wirewound Surface Mount Inductor 330 nH ±5% 310 mA Idc Q:48 36502AR33JTDG
Specifications
| Country of Origin | Taiwan |
|---|---|
| Brand | ATC |
| Height | 1.52mm |
| Length | 2.29mm |
| Model | 36502AR33JTDG |
| Depth | 1.73mm |
| Packaging | Reel |
| Series | 3650 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 330nH |
| Standards/Approvals | RoHS |
| Package/Case | 0805 |
| Maximum DC Current | 310mA |
| Pin Count | 2 |
| Maximum DC Resistance | 1.4Ω |
| Inductance Tolerance | ±5 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 600MHz |
| Minimum Quality Factor | 48 |
| Inductor Construction | Wirewound |
Key Features
- Compact 0805 package suitable for high-density PCB layouts.
- Ferrite core enhances magnetic properties and efficiency.
- Maximum DC current rating of 310 mA ensures reliable performance.
- High quality factor of 48 reduces signal losses at high frequencies.
- Maximum self-resonant frequency of 600 MHz supports high-frequency applications.
- Wirewound construction provides stable inductance and durability.
- RoHS compliant, moulded design for environmental safety and mechanical protection.
- Operating temperature range from -40°C to 125°C for broad usage.
Product Description
ATC 36502AR33JTDG is an 0805 format unshielded wirewound surface mount inductor featuring a ferrite core. It offers an inductance of 330 nH with a tight tolerance of ±5% and supports a maximum DC current of 310 mA, making it suitable for precision electronic circuits.
The inductor has a compact size with dimensions of 2.29 mm length, 1.52 mm height, and 1.73 mm depth, designed in the industry-standard 0805 package. Its wirewound construction enhances reliability and stable inductance value, while the ferrite core improves magnetic efficiency.
This component supports high-frequency applications with a maximum self-resonant frequency of 600 MHz and maintains a high quality factor of 48, ensuring minimal signal loss. The operating temperature ranges from -40°C to 125°C, suitable for a wide range of industrial, commercial, and automotive electronics.
Termination is via soldering for secure mounting, and the product is moulded to assure mechanical stability. It complies with RoHS standards, adhering to environmental regulations.
Its compact footprint, robust construction, and enhanced electrical characteristics make it ideal for use in high-density printed circuit boards, power management modules, and RF circuits across industrial, telecommunications, and consumer electronics sectors.
Compact 0805 package for space-saving PCB layout. Ferrite core enhances inductance performance. Supports maximum DC current of 310 mA. High quality factor of 48 reduces energy losses. Maximum self-resonant frequency of 600 MHz.
Wirewound, moulded construction for durability. RoHS compliant for environmental safety. Operating temperature from -40°C to 125°C. Solder termination style for reliable mounting. Explore more Surface Mount Inductors from ATC and other premium brands on EnvMart to fulfill your electronic component requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features an inductance value of 330 nH with a tolerance of ±5%.
The maximum DC current rating for this inductor is 310 mA.
It supports a maximum self-resonant frequency of 600 MHz, making it suitable for high-frequency applications.
The dimensions are 2.29 mm in length, 1.52 mm in height, and 1.73 mm in depth.
The operating temperature range is from -40°C to 125°C.
It features a wirewound construction, which provides stable inductance and durability.
The termination style for this model is solder, ensuring secure mounting on PCBs.
It has a minimum quality factor of 48, which helps reduce signal losses at high frequencies.
The core material is ferrite, which enhances the inductance performance.
Yes, this product is RoHS compliant, adhering to environmental safety standards.
It is packaged in a reel, suitable for automated assembly processes.
This model belongs to the 3650 series of inductors.
