SMC 5 mm Double Acting Cylinder CQ2 Series Through Hole Mount Aluminium Alloy Body CQ2B20-5DC
Specifications
| Country of Origin | China |
|---|---|
| Brand | SMC |
| Body Material | Aluminium Alloy |
| Model | CQ2B20-5DC |
| Mount Type | Through Hole |
| Series | CQ2 |
| Maximum Operating Temperature | 70°C |
| Stroke Length | 5mm |
| Rod Type | Single |
| Action Type | Double Acting |
| Piston Rod Gender | Female |
| Piston Rod Thread Standard | Metric |
Key Features
- Constructed with a durable aluminium alloy body for enhanced strength and corrosion resistance.
- Through hole mount type enables versatile installation options in pneumatic systems.
- Double acting operation provides both pushing and pulling motions with single rod design.
- Equipped with female metric piston rod thread for standardized fitting.
- Supports a maximum piston speed of 500 mm/s, suitable for precise motion control.
- Operates efficiently at temperatures up to 70°C ensuring reliability in industrial environments.
- Lightweight design reduces machine weight by 5-13% depending on model, improving productivity.
- Ideal for industrial pneumatic applications requiring compact actuators.
Product Description
SMC CQ2B20-5DC is a 5 mm stroke double acting pneumatic cylinder of the CQ2 Series featuring a robust aluminium alloy body with a through hole mount. This compact pneumatic piston rod cylinder is engineered to minimize overall machine weight and optimize productivity with weight reductions of 5 - 13% depending on model. It provides reliable double acting motion with a single rod, female metric-threaded piston rod, and operates at temperatures up to 70°C.
The maximum piston speed is rated at 500 mm/s, making it suitable for various industrial automation and fluid power applications including manufacturing, mechanical machinery, and pneumatic equipment. The compact design saves space and fits flexibly into pneumatic systems requiring precision actuation.
The aluminium alloy construction enhances durability and resistance to corrosion, fitting demanding industrial conditions. The through hole mount type offers flexible mounting options to suit different assembly requirements.
Durable aluminium alloy body construction. 5 mm stroke length suitable for precision motion. Through hole mount for flexible installation. Double acting with single rod providing bidirectional movement. Female piston rod with metric thread standard.
Maximum piston speed of 500 mm/s. Maximum operating temperature 70°C. Compact, lightweight design reduces machine weight and improves productivity.
This cylinder is ideal for industrial, manufacturing, and mechanical use cases involving pneumatic actuators and automated machinery. The CQ2 Series combines functionality with ease of installation, making it a preferred choice for fluid power applications.
Explore the full range of Pneumatic Piston Rod Cylinders for enhanced automation solutions with SMC's reliable engineering. Available with standard metric piston rod threads and versatile mounts to suit your operational needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The stroke length of the CQ2B20-5DC cylinder is 5 mm.
This model features a through hole mount type, allowing for versatile installation options in pneumatic systems.
The body of the CQ2B20-5DC is constructed from aluminium alloy, enhancing strength and corrosion resistance.
The maximum operating temperature for the CQ2B20-5DC is 70°C.
It supports a maximum piston speed of 500 mm/s, suitable for precise motion control.
This unit provides double acting operation, allowing for both pushing and pulling motions with a single rod design.
The piston rod features a female metric thread standard, ensuring compatibility with standardized fittings.
This model's lightweight design reduces machine weight by 5-13%, depending on the specific model.
It is ideal for industrial pneumatic applications, including manufacturing, mechanical machinery, and pneumatic equipment.
The compact design saves space and allows for flexible fitting into pneumatic systems requiring precision actuation.
This cylinder features a single rod type, which is typical for double acting cylinders.
The country of origin for this model is China.
